POWER CONNECTIONS
UNPACKING
When using a power tool at a considerable distance from a power source, be sure to use an extension cord that has the capacity to
handle the current the tool will draw. An undersized cord will cause a drop in line voltage, resulting in overheating and loss of power.
Use the chart to determine the minimum wire size required in an extension cord. ONLY round jacketed cords listed by Underwriter’s
Laboratories (UL) should be used.
Compare all parts to the list below and check that all parts are present and in good condition. Report any missing or damaged parts
to your distributor or dealer. Prior to tool assembly and use, read this manual thoroughly to familiarize yourself with proper assembly,
maintenance and safety procedures.
NOTE: Before using any extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
** Ampere rating (on total data label)
5A and less
Cord Length Wire Size
25' 16 AWG
50' 16 AWG
** Used on 12 gauge - 20 amp circuit
NOTE: AWG = American Wire Gauge
EXTENSION CORDS
KEEP the extension cord clear of the work
area. Position the cord so that it will not get caught on lumber,
tools or other obstructions while you are working with a power
tool. Failure to do so can result in serious personal injury. Check
extension cords before each use. If damaged replace
immediately. NEVER use tool with a damaged cord, since
touching the damaged area could cause electrical shock
resulting in serious injury.
23-196 6 inch Grinder or 23-197 8 inch Grinder
Eye Shields (2)
Spark Shields (2)
Flat Tool Rest (1)
Beveled Tool Rest (1)
PC1
PC1
PC2
PC2
PC3
PC3
PC4
PC4
PC6
PC6
PC5
PC5
PC7
PC7
PC8
PC8
PACKAGE CONTENTS
Wheel Dressing Tool (1)
Tool Rest Supports (2)
Coolant Tray (1)
To Next Page
