17
GENERAL CUTTING OPERATIONS
1. Your machine has the capacity to cut standard 2 x 4’s, lying flat or on edge, at the 45° right and left miter angles (Fig. A1 & A2).
2. A standard 2 x 6 can be cut in the 90° straight cut-off position in one pass (Fig. A3).
3. Cutting a standard 4 x 4 can be accomplished with one pass (Fig. A4).
4. This machine has the capacity to accurately cut crown mouldings and other bevel-type cuts (Fig. A5).
5. Cutting various sizes of plastic pipe is an easy job with this machine (Fig. A6). Material must be CLAMPED OR HELD FIRMLY
TO THE FENCE TO KEEP IT FROM ROLLING.
This is extremely important when making angle cuts.
A1 A2
A3
A4
A5
A6
