4.3.3 Installing a Removable Terminal Block
For AS200 / AS300 Series PLC CPU: install the removable terminal block on the module as shown below.

Installation
Align the terminal block at the printed circuit board, and press it into the module.

Removal
Pull the clips down in the direction shown by the arrow, and then pull the terminal block up as shown
below.
