Delta Hikvision DS-2FP2020 User Manual

User Manual
Code: DS-2FP2020
AUDIO MODULE DS-2FP2020 Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2020-10-10 DS-2FP2020 2/5
Bandwidth: 20 Hz ... 20 kHz
Operation area: max. 70 m²
Gain adjustment:
Power supply: 12 V DC
Current consumption: 25 mA (typical)
Output impedance: 600 Ω
Housing: Plastic
Main features:
• SNR : 60 dB
• Very good sensitivity of the microphone
• Digital Noise Reduction
• Auto Gain Control
• Sensitivity adjustment
• Dynamic range : 70 dB (1kHz @ max. 1dB SPL)
Operation temp: -30 °C ... 70 °C
Weight: 0.070 kg
Dimensions: Ø 78 x 26 mm
Manufacturer / Brand: Hikvision
SAP Code: 304900041
Guarantee:
3 years
The device is tiny sizes:

Delta Hikvision DS-2FP2020 Specifications

General

Brand	Delta
Model	Hikvision DS-2FP2020
Category	Control Unit
Language	English
