Dry Contact B
Dry Contact A
M30A_230 提供兩組乾接點端子，可依據變流器運行狀態控制外部裝置。該功能
的接線端子如圖3-21所示，圖中標示為兩組乾接點端子位置，乾接點為常開狀態，
其動作方式定義，使用者可藉由APP或DSS進行設定。
3.6.4 乾接點連接說明
圖 3-21 : 乾接點連接位置圖
107
安裝
