4.4. 通讯接口之连接
RPI-M15A/ M20A机种之通讯模块请参考图4-6。
此模块提供VCC、RS-485、dry contact、以及EPO等不同功能之连接端子。
图4-6 通讯模块示意图
Terminal Resistor
Dry contact
(3A / 28V)
RS-485
VCC
GND
+
-
+
-
EPO
(Emergency Power off)
71
