Delta TS350 User Manual

7 - English
1. Table Saw
2. Extension Wing (2)
3. Rip Fence
4. Miter Gauge
5. Rip Fence Handle
6. Handwheel Lock Knob (2)
7. M10 Flat Washer (2)
8. Handwheel (2)
9. Right Front Rail
10. Left Front Rail
11. Rail Extension Connector
12. Right Rear Rail
13. Left Rear Rail
14. Saw Blade
15. Blade Guard and Splitter Assembly
CARTON CONTENTS
For Blade Guard and Splitter Assembly
1. Splitter Bracket
2. 5/8" Flat Washer (2)
3. M12 x 1.75 Hex Nut (2)
4. M6 x 1x20mm Hex Head Screw
5. 1/4" External. Tooth Lockwasher (2)
6. 5/16" Flat Washer (2)
7. M6 x 1 Wing Nut
8. 13mm Open End Wrench
9. 15/16" Hex Arbor Wrench
For Front Guide Rail
10. M6 x 1x20mm Carriage Head Screw (5)
11. M6.4 Flat Washer (5)
12. M6.1 Lockwasher (5)
Fig. A
Fig. B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
22
21
333
13. M6 x 1 Hex Nut (5)
For Fastening Saw to Stand
14. M8 x 1.25 x 16mm Hex Head Screws (4)
15. 3/8" Flat Washer (8)
16. M8 x 1.25 Hex Nut (4)
For Rear Guide Rail
17. M8 x 1.25x16mm Hex Head Screw (5)
18. M8.4 Flat Washer (5)
19. M8.1 Lockwasher (5)
For Extension Wings
20. - M8x1.25x16mm Hex Head Screw (6)
21. - 5/16" Lockwasher (6)
22. - 3/8" Flat Washer (6)
