Appendix B Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08 B-9
Remove any paint on metal saddle for good ground contact with
the plate and shielding.
saddle
the plate with grounding
Saddle on both ends
Saddle on one end
