Delta VFD007B21A User Manual

Appendix B Accessories_VFD-B Series
B-30 Revision 10/2005, BE13, SW V4.08
B.6 AC Reactor
B.6.1 AC Input Reactor Recommended Value
230V, 50/60Hz, 1-Phase
Inductance (mH)
kW
HP
Fundamental
Amps
Max. continuous
Amps
3~5% impedance
0.75
1 8 12 1.5
1.5
2 12 18 1.25
2.2
3 18 27 0.8
460V, 50/60Hz, 3-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
0.75 1 4 6 9 12
1.5 2 4 6 6.5 9
2.2 3 8 12 5 7.5
3.7 5 8 12 3 5
5.5 7.5 12 18 2.5 4.2
7.5 10 18 27 1.5 2.5
11 15 25 37.5 1.2 2
15 20 35 52.5 0.8 1.2
18.5 25 35 52.5 0.8 1.2
22 30 45 67.5 0.7 1.2
30 40 55 82.5 0.5 0.85
37 50 80 120 0.4 0.7
45 60 80 120 0.4 0.7
55 75 100 150 0.3 0.45
75 100 130 195 0.2 0.3
575V, 50/60Hz, 3-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
0.75 1 2 3 20 32
1.5 2 4 6 9 12
2.2 3 4 6 9 12
3.7 5 8 12 5 7.5
5.5 7.5 8 12 3 5
7.5 10 12 18 2.5 4.2
11 15 18 27 1.5 2.5
