Delta VFD007B23A User Manual

Appendix B Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08 B-31
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
15 20 25 37.5 1.2 1.8
18.5 25 25 37.5 1.2 1.8
22 30 35 52.5 0.8 1.2
30 40 45 67.5 0.7 1.2
37 50 55 82.5 0.5 0.85
45 60 80 120 0.4 0.7
55 75 80 120 0.4 0.7
75 100 100 150 0.3 0.45
B.6.2 AC Output Reactor Recommended Value
230V, 50/60Hz, 3-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
0.75
1 8 12 3
5
1.5
2 8 12 1.5
3
2.2
3 12 18 1.25
2.5
3.7
5 18 27 0.8
1.5
5.5
7.5 25 37.5 0.5
1.2
7.5
10 35 52.5 0.4
0.8
11
15 55 82.5 0.25
0.5
15
20 80 120 0.2
0.4
18.5
25 80 120 0.2
0.4
22
30 100 150 0.15
0.3
30
40 130 195 0.1
0.2
37
50 160 240 0.075
0.15
460V, 50/60Hz, 3-Phase
Inductance (mH)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
0.75
1
4 6 9 12
1.5
2
4 6 6.5 9
2.2
3
8 12 5 7.5
3.7
5
12 18 2.5 4.2
