Chapter 1 Introduction_VFD-B Series

1-2

Revision 10/2005, BE13, SW V4.08

1.1.3 Series Number Explanation

0150T007B23A

Production number

Production year 2005

Production factory

Production week

(Taoyuan)

Model

230V 3-phase 1HP(0.75kW)

If the nameplate information does not correspond to your purchase order or if there are any

problems, please contact your distributor.

1.1.4 Drive Frames

Frame Power range Models

1hp (0.75kW) VFD007B23A/43A/53A

1-2hp (0.75-1.5kW) VFD007B21A, VFD015B21A/23A/43A/53A

2-3hp (1.5-2.2kW) VFD015B21B/23B, VFD022B23B/43B/53A

3-5hp (2.2-3.7kW) VFD022B21A, VFD037B23A/43A/53A

7.5-15hp (5.5-11kW)

VFD055B23A/43A/53A, VFD075B23A/43A/53A,

VFD110B23A/43A/53A

20-30hp (15-22kW)

VFD150B23A/43A/53A, VFD185B23A/43A/53A,

VFD220B23A/43A/53A

40-60hp (30-45kW) VFD300B43A/53A, VFD370B43A/53A, VFD450B43A/53A

40-100hp (30-75kW)

VFD300B23A, VFD370B23A, VFD550B43C/53A,

VFD750B43C/53A

75-100hp (55-75kW) VFD550B43A, VFD750B43A

Please refer to Chapter 2.3 for exact dimensions.

1.2 Appearances

(Refer to chapter 2.3 for exact dimensions)
