Appendix B Accessories_VFD-B Series

B-36 Revision 10/2005, BE13

B.8 DC Choke Recommended Values

230V DC Choke

Input voltage kW HP DC Amps Inductance (mh) MTE CAT. NO

0.75 1 9 7.50 9RB003

1.5 2 12 4.00 12RB003

2.2 3 18 2.75 18RB003

3.7 5 25 1.75 25RB004

5.5 7.5 32 0.85 32RB001

7.5 10 40 0.75 40RB002

11 15 62 0.61 62RB002

15 20 92 0.60 92RB002

18.5 25 110 0.30 110RB002

22 30 125 0.22 125RB002

30 40 -- Built-in --

230Vac

50/60Hz

3-Phase

37 50 -- Built-in --

0.75 1 9 12.00 --

1.5 2 12 8.00 --

230Vac

50/60Hz

1-Phase

2.2 3 18 6.00 --
