VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-7
Group 3 Output Function Parameters
Parameters Explanation Settings
Factory
Setting
00: Not Used
01: AC Drive Operational
02: Master Freq. Attained
03-00
Multi-Function Output
Terminal (Relay Output)
03: Zero Speed
04: Over Torque Detection
05: Base-Block (B.B.) Indication
06: Low-Voltage Indication
03-01
Multi-Function Output
Terminal MO1
07: AC Drive Operation Mode
08: Fault Indication
09: Desired Freq. Attained 1
10: PLC Program Running
03-02
Multi-Function Output
Terminal MO2
11: PLC Program Step Completed
12: PLC Program Completed
13: PLC Program Operation Paused
14: Terminal Count Value Attained
15: Preliminary Count Value Attained
16: Auxiliary Motor No.1
17: Auxiliary Motor No.2
18: Auxiliary Motor No.3
19: Heat Sink Overheat Warning
20: AC Drive Ready
21: Emergency Stop Indication
22: Desired Frequency Attained 2
23: Soft Braking Signal
24: Zero Speed Output Signal
25: Low-current Detection
26: Operation indication (H>=Fmin)
27: Feedback signal error
28: User-defined low-voltage Detection
03-03
Multi-Function Output
Terminal MO3
00: No functions
08
01
02
20
03-04 Desired Freq. Attained 1 0.00 to 400.00 Hz 0.00
00: Output frequency
01: Output current
02: Output voltage
03: Output frequency command
04: Output motor speed
03-05 Analog Output Signal
05: Load power factor
00
03-06 Analog Output Gain  01 to 200% 100
