Chapter 16 PLC Function ApplicationsC2000 Plus
16-166
16-13 Calendar function
The C2000 Plus's internal PLC includes calendar functions, but these may only be used when a
keypad (KPC-CC01) is connected, otherwise the function cannot be used. Currently-supported commands
include TCMP (comparison of calendar data), TZCP (calendar data range comparison), TADD (calendar
data addition), TSUB (calendar data subtraction), and TRD (calendar reading). Please refer to the
explanation of relevant commands and functions for the usage of these commands.
In real applications, the internal PLC can judge whether calendar function have been activated; if they
have been activated, calendar warning codes may be displayed in some situations. The basis for whether
a calendar function has been activated is whether the program has written the calendar time (D1063 to
D1069) in connection with the foregoing calendar commands or programs.
The calendar's time display is currently assigned to D1063 to D1069, and is defined as follows:
Special D Item Content
A
ttributes
D1063
Year
(Western)
20xx (2000–2099) RO
D1064 Weeks 1–7 RO
D1065 Month 1–12 RO
D1066 Day 1–31 RO
D1067 Hour 0–23 RO
D1068 Minute 0–59 RO
D1069 Second 0–59 RO
Calendar-related special M items are defined as follows:
Special D Item
A
ttributes
M1068 Calendar time error RO
M1076
Calendar time error or refresh time
out
RO
M1036 Ignore calendar warning RW
NOTE:
1. When a program write
s to the commands TCMP, TZCP, TADD, or TSUB, if it is di
scovered that a
value exceeds the reasonable range, M1026 will be 1.
2.
When the keypad display is PLra (RTC correction warning) or PLrt (RTC time out warning),
M1076 will be ON.
3.
When M1036 is 1, the
PLC will ignore the calendar warning.
Calendar trigger warning code is defined as follows:
Warning Description Reset approach Whether it affects PLC operation
PLra Calendar time correction Requires power restart
Will not have any effect
PLrt Calendar time refresh time out Requires power restart
Will not have any effect
NOTE:
1. When the PLC's calen
dar functions are operating, if the keypad is replaced with a
nother keypad,
it will jump to PLra.
2.
When it is discovered at startup th
at the keypad has not been powered for more than 7 days, or
the time is wrong, PLra will be triggered.
3.
When it is discovered
that the C2000 Plus has
no keypad in 10 sec. after startup, PLrt will be
triggered.
