Chapter 9 Specification C2000 Plus
9-13
9-6 Specification for Operation Temperature and Protection Level
Model Frame
Top
cover
Conduit
Box
Protection Level
Operation
Temperature
VFDxxxCxxx-21
Frame A–C
230V: 0.75–22 kW
460V: 0.75–30 kW
575V: 1.5~15 kW
690V: 18.5–37 kW
Top
cover
removed
Standard
conduit
plate
IP20 / UL Open Type -10–50°C
Standard
with top
cover
IP20 / UL Type1 / NEMA1 -10–40°C
VFDxxxCxxx-21
Frame D0–H
230V: ≥ 22 kW
460V: ≥ 37 kW
690V: ≥ 45 kW
N/A
Standard
conduit
box
IP20 / UL Type1 / NEMA1 -10–40°C
VFDxxxCxxx-00
Frame D0–H
230V: ≥ 22 kW
460V: ≥ 37 kW
690V: ≥ 45 kW
N/A
No
conduit
box
IP00
IP20 / UL Open Type
The circled area: IP00
Other than the circled area: IP20
Figure 9-1
-10–50°C
Table 9-10
