Chapter 7 Optional AccessoriesMS300
7-10
7-3 Fuse Specification Chart
 Fuse specifications lower than the table below are allowed.
 For installation in the United States, branch circuit protection must be provided in accordance with the
National Electrical Code (NEC) and any applicable local codes. Use UL classified fuses to fulfill this
requirement.
 For installation in Canada, branch circuit protection must be provided in accordance with Canadian
Electrical Code and any applicable provincial codes. Use UL classified fuses to fulfill this requirement.
Model Voltage / One-phase (Three-phase) Branch Circuit Fuses Output [A]
VFD1A6MS11ANSAA
VFD1A6MS11ENSAA
115V / One-phase
7.2
Class T JJS-10 600 V
AC
VFD2A5MS11ANSAA
VFD2A5MS11ENSAA
10.8
Class T JJS-10 600 V
AC
VFD4A8MS11ANSAA
VFD4A8MS11ENSAA
22
Class T JJS-25 600 V
AC
VFD1A6MS21ANSAA
VFD1A6MS21ENSAA
VFD1A6MS21AFSAA
230V / One-phase
7.2
Class T JJS-10 600 V
AC
VFD2A8MS21ANSAA
VFD2A8MS21ENSAA
VFD2A8MS21AFSAA
12.8
Class T JJS-15 600 V
AC
VFD4A8MS21ANSAA
VFD4A8MS21ENSAA
VFD4A8MS21AFSAA
20
Class T JJS-20 600 V
AC
VFD7A5MS21ANSAA
VFD7A5MS21ENSAA
VFD7A5MS21AFSAA
34
Class T JJS-35 600 V
AC
VFD11AMS21ANSAA
VFD11AMS21ENSAA
VFD11AMS21AFSAA
50
Class T JJS-50 600 V
AC
VFD1A6MS23ANSAA
VFD1A6MS23ENSAA
230V / Three-phase
7.2
Class T JJS-10 600 V
AC
VFD2A8MS23ANSAA
VFD2A8MS23ENSAA
12.8
Class T JJS-15 600 V
AC
VFD4A8MS23ANSAA
VFD4A8MS23ENSAA
20
Class T JJS-20 600 V
AC
VFD7A5MS23ANSAA
VFD7A5MS23ENSAA
32
Class T JJS-35 600 V
AC
VFD11AMS23ANSAA
VFD11AMS23ENSAA
50
Class T JJS-50 600 V
AC
VFD17AMS23ANSAA
VFD17AMS23ENSAA
78
Class T JJS-80 600 V
AC
VFD25AMS23ANSAA
VFD25AMS23ENSAA
59.4
Class T JJS-60 600 V
AC
VFD33AMS23ANSAA
VFD33AMS23ENSAA
79.2
Class T JJS-80 600 V
AC
VFD49AMS23ANSAA
VFD49AMS23ENSAA
112.2
Class T JJS-110 600 V
AC
VFD65AMS23ANSAA
VFD65AMS23ENSAA
151.8
Class T JJS-150 600 V
AC
