Chapter 7 Optional AccessoriesMS300
7-38
7-6 EMC Filter
Use EMC filters to enhance the EMC performance for the environment and machines and to comply
with EMC regulations, further reducing EMC problems. If you purchase a motor drive without a built-in
EMC filter, it is recommended that you select the EMC filters as shown below. For some motor drive
models, you need to work with zero phase reactors to be compliant with EMC regulations. Refer to the
table and figure below for the recommended model, setting method, and maximum motor cable length of
the EMC filter and zero phase reactor.
Frame
Motor Drive
Model #
Input
Current
(A)
Filter Model #
Recommended Model of
Zero Phase Reactors
Conducted
Emission
Maximum Motor
Cable Length
Radiated
Emission
Maximum Motor
Cable Length
C1
30 m
C2
100 m
C2
100 m
Position to install a zero phase reactor
DELTA
VAC
○
R
*1 *2 *3 N/A *1 *2 *3
A VFD1A6MS11ANSAA 6.8 EMF11AM21A RF008X00A T60006L2040W453 NA
A VFD1A6MS21ANSAA 3.8 EMF11AM21A RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
A VFD2A8MS21ANSAA 6.7 EMF11AM21A RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
A VFD1A6MS23ANSAA 2.2 EMF10AM23A RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
A VFD2A8MS23ANSAA 3.8 EMF10AM23A RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
A VFD4A8MS23ANSAA 6 EMF10AM23A RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
A VFD1A5MS43ANSAA 2.5 EMF6A0M43A RF008X00A T60006L2040W453 ✓ NA ✓
A VFD2A7MS43ANSAA 4.2 EMF6A0M43A RF008X00A T60006L2040W453 ✓ NA ✓
A VFD1A7MS53ANSAA 2.4 EMF6A0M63B RF008X00A T60006L2040W453 NA*
A VFD2A5MS11ANSAA 10.1 EMF11AM21A RF008X00A T60006L2040W453 NA
B VFD4A8MS21ANSAA 10.5 EMF11AM21A RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
B VFD7A5MS23ANSAA 9.6 EMF10AM23A RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
B VFD3A0MS53ANSAA 4.2 EMF6A0M63B RF008X00A T60006L2040W453 NA*
B VFD4A2MS43ANSAA 6.4 EMF6A0M43A RF008X00A T60006L2040W453 ✓ NA ✓
C VFD4A8MS11ANSAA 20.6 EMF27AM21B RF008X00A T60006L2040W453 NA
C VFD7A5MS21ANSAA 17.9 EMF27AM21B RF008X00A T60006L2040W453 ✓ NA ✓
C VFD11AMS21ANSAA 26.3 EMF27AM21B RF008X00A T60006L2040W453 ✓ NA ✓
C VFD11AMS23ANSAA 15 EMF24AM23B RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
C VFD17AMS23ANSAA 23.4 EMF24AM23B RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
C VFD5A5MS43ANSAA 7.2 EMF12AM43B RF008X00A T60006L2040W453 NA
C VFD4A2MS53ANSAA 5.8 EMF16AM63B RF008X00A T60006L2040W453 NA*
C VFD6A6MS53ANSAA 9.3 EMF16AM63B RF008X00A T60006L2040W453 NA
C VFD7A3MS43ANSAA 8.9 EMF12AM43B RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
C VFD9A0MS43ANSAA 11.6 EMF12AM43B RF008X00A T60006L2040W453 ✓ ✓ NA ✓ ✓
D VFD25AMS23ANSAA 32.4 EMF33AM23B RF008X00A T60006L2050W565 ✓ ✓ NA ✓ ✓
D VFD13AMS43ANSAA 17.3 EMF23AM43B RF008X00A T60006L2050W565 ✓ ✓ ✓ NA ✓ ✓ ✓
D VFD9A9MS53ANSAA 13.4 EMF16AM63B RF008X00A T60006L2040W453 N/A
D VFD9A9MS53ANSAA 17.5 EMF16AM63B RF008X00A T60006L2040W453 N/A
D VFD17AMS43ANSAA 22.6 EMF23AM43B RF008X00A T60006L2050W565 ✓ ✓ ✓ NA ✓ ✓ ✓
E VFD33AMS23ANSAA 43.2 B84143D0075R127 RF008X00A T60006L2050W565 ✓ ✓ NA ✓ ✓
E VFD49AMS23ANSAA 61.2 B84143D0075R127 RF008X00A T60006L2050W565 ✓ ✓ NA ✓ ✓
E VFD25AMS43ANSAA 30.8 B84143D0050R127 RF008X00A T60006L2050W565 NA
E VFD32AMS43ANSAA 39.6 B84143D0050R127 RF008X00A T60006L2050W565 ✓ ✓ NA ✓ ✓
F VFD65AMS23ANSAA 82.8 B84143D0090R127 RF008X00A T60006L2050W565 ✓ ✓ NA ✓ ✓
F VFD38AMS43ANSAA 45.7 B84143D0075R127 RF008X00A T60006L2050W565 ✓ ✓ NA ✓ ✓
F VFD45AMS43ANSAA 53.9 B84143D0075R127 RF008X00A T60006L2050W565 ✓ ✓ NA ✓ ✓
Note 1: It is not necessary to add a zero phase reactor for passing the C2 conducted emission test.
The maximum motor cable length of the conducted emission C2 class for VFD1A7MS53ANSAA, VFD3A0MS53ANSAA and
VFD4A2MS53ANSAA is 75 m, others are 100 m.
Table 7-6-1
