q Digital audio connectors
(OPTICAL / COAXIAL) ·························· (12, 13)
w Analog audio connectors (AUDIO) ············ (12)
e EXT. IN connectors ····································· (15)
r REMOTE CONTROL jacks··························· (17)
t PRE OUT connector ······································ (9)
y ZONE2 connectors······································ (17)
u AC OUTLETS ··············································· (17)
i Power cord ·················································· (17)
o Speaker terminals (SPEAKERS) ·················· (9)
Q0 FM/AM antenna terminals
(TUNER ANTENNA) ···································· (16)
Q1 COMPONENT VIDEO connectors ·············· (12)
Q2 HDMI connectors ·········································(11)
Q3 VIDEO / S-VIDEO connectors ···················· (12)
Q4 XM connector (SAT TU) ······························ (16)
Q5 DOCK CONTROL jack ································· (13)
Rear Panel
