AVR-4806 / AVC-A11XV
28 P77 NC O C - - - Z O/L O/L Not used
29 P76 NC O C - - - Z O/L O/L Not used
30 P75 NC O C - - - Z O/L O/L Not used
31 P74 VIDEO POWER O C - - Ed Z O/L O/L
VIDEO POWER control pin(ON="H",OFF="L")
32 P73/CTS2 REQ VOMI O C - - - Z O/L O/L
MAIN-VIDEO μcom comm. control pin
33 P72/CLK2 CLK VIMO I - Lv - - Z I O/L
MAIN-VIDEO μcom comm. control pin
34 P71/RXD2 VIMO I - Lv - - Z I O/L
MAIN-VIDEO μcom comm. control pin
35 P70/TXD2 VOMI O N - - Eu Z O/L O/L
MAIN-VIDEO μcom comm. control pin
36 P67/TXD1/SDA1 5V SDA/TxD I/O C - - - Z O/L O/L HDMI IC control/Data transfer pin to outside(MAKER BOOT)
37 VCC1 VCC - - - - - - - - +5V
38 P66/RXD1/SCL1 5V SCL/RxD I/O C - - - Z O/L O/L HDMI IC control/Data transfer pin from outside(MAKER BOOT)
39 VSS VSS - - - - - - - - GND
40 P65/CLK1 (Y/C SEL) O C - - Ed Z O/L O/L Not used
41 P64/CTS1 NC O C - - - Z O/L O/L Not used
42 P63/TXD0/SDA0 EDIT SDA I/O C - - Eu Z O/L O/L HDMI/DVI EDIT(E2PROM) control pin
43 P62/RXD0/SCL0 EDIT SCL I/O C - - Eu Z O/L O/L HDMI/DVI EDIT(E2PROM) control pin
44 P61/CLK0 NC O C - - - Z O/L O/L Not used
45 P60/CTS0 NC O C - - - Z O/L O/L Not used
46 P137 NC O C - - - Z O/L O/L Not used
47 P136 NC O C - - - Z O/L O/L Not used
48 P135 NC O C - - - Z O/L O/L Not used
49 P134 NC O C - - - Z O/L O/L Not used
50 P57 NC O C - - - Z O/L O/L Not used
51 P56 NC O C - - - Z O/L O/L Not used
52 P55/EPM FRASH EPM I - Lv - Eu Z I I Rewrite boot program start: L input set
53 P54 NC O C - - - Z O/L O/L Not used
54 P133 NC O C - - - Z O/L O/L Not used
55 P132 NC O C - - - Z O/L O/L Not used
56 P131 NC O C - - - Z O/L O/L Not used
57 P130 NC O C - - - Z O/L O/L Not used
58 P53 NC O C - - - Z O/L O/L Not used
59 P52 NC O C - - - Z O/L O/L Not used
60 P51 NC O C - - - Z O/L O/L Not used
61 P50/CE FRASH CE I - - - Ed Z I I Rewrite boot program start: H input set
62 P127 Z1 SMONIDET1 I - - - Eu Z I O/L MAIN ZONE's S-monitor connection detect input (Connected:L )
63 P126 Z1 VSIG DET I - Lv - Eu Z I O/L
MAIN ZONE's VIDEO signal detect port（Detected:H)
64 P125 NC O C - - - Z O/L O/L Not used
65 P47 NC O C - - - Z O/L O/L Not used
66 P46 NC O C - - - Z O/L O/L Not used
67 P45 S EXP CLK O C - - - Z O/L O/L Video switching expander control for S/CVBS(BU4094B)
68 P44 S EXP DATA O C - - - Z O/L O/L Video switching expander control for S/CVBS(BU4094B)
69 P43 S EXP STB O C - - - Z O/L O/L Video switching expander control for S/CVBS(BU4094B)
70 P42 S EXP OE O C - - Ed Z O/L O/L Video switching expander control for S/CVBS(BU4094B)
71 P41 NC O C - - - Z O/L O/L Not used
72 P40 NC O C - - - Z O/L O/L Not used
73 P37 NC O C - - - Z O/L O/L Not used
74 P36 NC O C - - - Z O/L O/L Not used
75 P35 NC O C - - - Z O/L O/L Not used
76 P34 HDMI O C - - - Z O/L O/L HDMI output control pin(HDMI)
77 P33 RGB O C - - - Z O/L O/L HDMI output control pin(RGB)
78 P32 YUV O C - - - Z O/L O/L HDMI output control pin(YUV)
79 P31 Z1 SYNC DET I - Lv - Eu Z I I Sync. detect input for MAINZONE (H: Ext. synchronized)
80 P124 Z1 OSD RST O C - - - Z O/L O/L OSD control for MAINZONE (M35015)
81 P123 NC O C - - - Z O/L O/L Not used
82 P122 NC O C - - - Z O/L O/L Not used
83 P121 C EXP CLK O C - - - Z O/L O/L Video switching expander control for COMPONENT(BU4094B)
84 P120 C EXP DATA O C - - - Z O/L O/L Video switching expander control for COMPONENT(BU4094B)
85 VCC2 VCC2 - - - - - - - - +5V
86 P30 (PAL ENA.) I - Lv - Eu Z I O/L Not used (DECODE correspondence/ non-correspondence detect
(noncorrespondence:L))
87 VSS VSS - - - - - - - - GND
88 P27 C EXP STB O C - - - Z O/L O/L Video switching expander control for COMPONENT(BU4094B)
89 P26 C EXP OE O C - - Ed Z O/L O/L Video switching expander control for COMPONENT(BU4094B)
90 P25 COMP SDET1 I - Lv - Eu Z I O/L MAIN ZONE's COMPONENT signal detect input
91 P24 NC O C - - - Z O/L O/L Not used
92 P23 P1HPRMV2 O C - - - Z O/L O/L HP(hot-plug) detect input for HDMI IN3 terminal
93 P22 POHPRMV2 O C - - - Z O/L O/L HP(hot-plug) detect input for HDMI IN2 terminal
94 P21 P1HPRMV1 O C - - - Z O/L O/L HP(hot-plug) detect input for HDMI IN1 terminal
95 P20 P0HPRMV1 O C - - - Z O/L O/L HP(hot-plug) detect input for DVI IN terminal
96 P17/INT5 HDMI SENS I -
E ↓ &L
- Eu Z I O/L HDMI signal detect input
97 P16/INT4 VD INT I -
E ↓ &L
- Eu Z I O/L VIDEO DECODER(ADV7403) INT signal detect input
98 P15/INT3 ACK VIMO I -
E ↓ &L
- - Z I O/L
MAIN-VIDEO μcom comm. control pin
99 P14 NC O C - - - Z O/L O/L Not used
100 P13 (H DDCRES) O C - - Ed Z O/L O/L HDMI MONITOR OUT DATA ON/OFF control pin
101 P12 NC O C - - - Z O/L O/L Not used
102 P11 HDMI T RST O C - - Ed Z O/L O/L HDMI TRANSMITTER reset (Si I9030)
