AVR-4806 / AVC-A11XV
103 P10 HDMI CS O - - - Ed Z O/L O/L HDMI TRANSMITTER chip select (Si I9030)
104 P07/AN07 NC O C - - - Z O/L O/L Not used
105 P06/AN06 NC O C - - - Z O/L O/L Not used
106 P05/AN05 VD RST O - - - - Z O/L O/L VIDEO DECODER reset (ADV7403)
107 P04/AN04 NC O C - - - Z O/L O/L Not used
108 P03/AN03 NC O C - - - Z O/L O/L Not used
109 P02/AN02 VE RST O - - - - Z O/L O/L VIDEO ENCODER reset (ADV7320)
110 P01/AN01 NC O C - - - Z O/L O/L Not used
111 P00/AN00 INT1 I - - - Eu Z I O/L HDMI RECEIVER(Si I9031)INT output (DVI IN1/HDMI IN1)
112 P117 INT2 I - - - Eu Z I O/L HDMI RECEIVER(Si I9031)INT output (HDMI IN2/IN3)
113 P116 HDMI R RST O C - - Ed Z O/L O/L HDMI RECEIVER reset (Si I9031) (HDMI IN2/IN3)
114 P115 DVI R RST O C - - Ed Z O/L O/L HDMI RECEIVER reset (Si I9031) (DVI IN1/HDMI IN1)
115 P114 SCDT1 I - - - Eu Z I O/L HDMI RECEIVER(Si I9031)SCDT output (DVI IN1/HDMI IN1)
116 P113 SCDT2 I - - - Eu Z I O/L HDMI RECEIVER(Si I9031)SCDT output (HDMI IN2/IN3)
117 P112 WP1 O C - - Ed Z O/L O/L HDMI IN1 EDIT(24LC02) WRITE PROTECT
118 P111 WP2 O C - - Ed Z O/L O/L HDMI IN1 EDIT(24LC02) WRITE PROTECT
119 P110 WP3 O C - - Ed Z O/L O/L HDMI IN1 EDIT(24LC02) WRITE PROTECT
120 P107/AN7 WP4 O C - - Ed Z O/L O/L HDMI IN1 EDIT(24LC02) WRITE PROTECT
121 P106/AN6 NC O C - - - Z O/L O/L Not used
122 P105/AN5 Z1 S SIG DET I - - - Eu Z I O/L MAIN ZONE's S-signal detect input (H: S-signal inputted)
123 P104/AN4 NC O C - - - Z O/L O/L Not used
124 P103/AN3 NC O C - - - Z O/L O/L Not used
125 P102/AN2 NC O C - - - Z O/L O/L Not used
126 P101/AN1 NC O C - - - Z O/L O/L Not used
127 AVSS AVSS - - - - - - - - AD GND
128 P100/AN0 NC O C - - - Z O/L O/L Not used
Pin Pin Name Symbol I/O Type Det
Op
(Int.)
Op
(Ext.)
Res STBY stop FUNCTION
Note: Pin No. : Terminal number of microcomputer.
Port Name : The name entered in the data sheet of microcomputer.
Symbol : Symbolized interface function.
I/O : Input or out of part.
“I” = Input port
“O” = Output port
Type : Composition of port in case of output port.
“C” = CMOS output
“N” = NMOS open drain output
“P” = PMOS open drain output
Op : Pull up/Pull down selection information.
“Iu” = Inner microcomputer pull up
“Id” = Inner microcomputer pull down
“Eu” = External microcomputer pull up
“Ed” = External microcomputer pull down
Det : Indicates judging state of input port. Level detection is “LV”; Edge detection is “Ed”; Detection by both shifting is “E&L”;
Serial data detection is “S” (Serial data output is also “S”).
Res : State at reset.
“H” = Outputs High Level at reset
“L” = Outputs Low Level at reset
“Z” = Becomes High impedance mode at reset
STBY : State of port when STANDBY mode.
“O/L” = Output port and “L”
“I” = Input port
Stop : State of port when Stop mode.
“O/L” = Output port and “L”
“I” = Input port
