17
AVR-1709/1609/1519/1509/689/589, AVC-1509
9. MAIN P.W.B SUB ASSY
Please refer to
"EXPLODED VIEW "
for the disassembly method of each P.W.B included in MAIN P.W.B ASSY .
MAINP.W.BASSY の各基板のはずしかたは "EXPLODEDVIEW" を参照してください。
10. POWER P.W.B SUB ASSY
(1) Disconnect the connector wires.（コネクタワイヤーをはずす。）
(2) Remove the screws.（ねじをはずす。）
proceeding (手順): CABINET TOP → HDMI P.W.B ASSY → SIRIUS P.W.B ASSY
→ TUNER PACK → SPEAKER P.W.B ASSY
→ CHASSIS BACK SUB ASSY → VIDEO P.W.B ASSY
→ INPUT / CPU P.W.B ASSY → MAIN P.W.B SUB ASSY
proceeding (手順): CABINET TOP → HDMI P.W.B ASSY → SIRIUS P.W.B ASSY
→ TUNER PACK → SPEAKER P.W.B ASSY
→ POWER P.W.B SUB ASSY
Picture C
cut
CP513CP512 CP501 CP503
CN506 CN505
POWER P.W.B ASSY
POWER SUPPLY P.W.B ASSY
Top view
