AVR-1604/684 / AVC-1580
INPUT-VOL P.W.B. UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC701 963 0096 401 IC BD3811K1
IC702 963 0114 503 IC BD3812F
IC721 963 0024 004 IC NJM2068M
IC761-763 963 0024 004 IC NJM2068M
IC781-784 963 0024 004 IC NJM2068M
Q751 963 0121 004 Transistor KRC104M
Q752 960 0097 207 Transistor KRA102M
Q753,754 960 0196 807 Transistor 2SK117Y
Q755 963 0121 004 Transistor KRC104M
Q756 960 0097 207 Transistor KRA102M
Q757,758 960 0196 807 Transistor 2SK117Y
Q771 963 0121 004 Transistor KRC104M
Q772 960 0097 207 Transistor KRA102M
Q773,774 960 0196 807 Transistor 2SK117Y
D751-754 963 0096 605 Diode 1N4148WS
D771,772 963 0096 605 Diode 1N4148WS
ZD701,702 960 0222 603 Zener diode MTZJ7.5A
RESISTORS GROUP
R731,732 244 2051 958 Metal film 220 ohm 1W
R771,772 244 2051 961 Metal film 100 ohm 1W
R791,792 244 2051 961 Metal film 100 ohm 1W
CAPACITORS GROUP
C701L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C702L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C703L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C704L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C705L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C706L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C707L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C708L,R 963 9004 575 Ceramic chip 100pF/50V E2,EK,E2A
C711L,R 963 9004 698 Ceramic chip 0.01uF/50V
C713L,R 963 9006 308 Electrolytic 10uF/50V
C714L,R 963 9003 152 Mylar film 0.068uF/100V
C715L,R 963 9003 152 Mylar film 0.068uF/100V
C716L,R 963 9006 308 Electrolytic 10uF/50V
C721 963 9006 447 Electrolytic 47uF/25V
C722 960 9004 602 Ceramic 0.047uF/50V
C723 963 9006 447 Electrolytic 47uF/25V
C724 960 9004 602 Ceramic 0.047uF/50V
C725,726 963 9005 736 Mylar film 0.0047uF/100V
C727-730 963 9004 766 Mylar film 0.1uF/100V
C731-736 963 9006 308 Electrolytic 10uF/50V
C741-743 963 9004 575 Ceramic chip 100pF/50V
C751 963 9006 379 Electrolytic 1uF/50V
C756 963 9006 379 Electrolytic 1uF/50V
C761FL,FR,SW 963 9004 753 Ceramic chip 0.047uF/50V
