Denon AVR-1609 Service Manual

101
AVR-1709/1609/1519/1509/689/589, AVC-1509
HDMI P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC01 00D2623721007 SIL9185
J040918500010S
IC03 00D9630367503 IC SE1117-1.8 J126111718010S
IC801 245810005005D IC ADSP-21367 J080213670020S *
IC802 246810009604S IC W9864G2GH-6
J001986460010S
IC803 963248000660D IC EN29LV160AB J005291600030S
IC807 00D2623449004 IC LC89057W-VF4A-E J046890570030S
IC808 237810004001D IC ADAU1328 J080132800000S
IC809-811 00D9600266805 IC 74LCX244MTCX J040742440180S
IC812 00D9600266902 IC MM74HCT244 J040742440190S
IC814,815 963236000670S IC SN74HCT00PWR J040740000210S
IC816 00D2622870904 IC 74LVX157 J040741570100S
IC825,826 963236000680S IC SN74LVC74APWR J040747400200S
IC832 90M-HC900100R IC SE1117-33-PF J126111733020S
Q01 00D9630120801 TR KRC102S AVR1709, 689 J522010200210S
Q02 00D9630120801 TR KRC102S J522010200210S
Q03 00D9600285006 TR KRC104S AVR1709, 689 J522104S00210S
Q04 00D9600285006 TR KRC104S J522104S00210S
Q05 00D9630120801 TR KRC102S J522010200210S
Q07 00D9600285006 TR KRC104S J522104S00210S
Q18 00D9600285006 TR KRC104S AVR1709, 689 J522104S00210S
Q19-21 00D9600285006 TR KRC104S J522104S00210S
Q810D 00D9630120801 TR KRC102S J522010200210S
Q811D 00D9630120704 TR KRA102S J520010200210S
Q814D 00D9630120704 TR KRA102S J520010200210S
D01-12 00D9630341305 D,ESD IMSA-6802-01A AVR1709, 689 K067680200010S
D13-15 00D9630341305 IC MM74HCT244 K067680200010S
D17-32 00D9630341305 IC MM74HCT244 K067680200010S
D34-36 00D9630341305 IC MM74HCT244 K067680200010S
D44 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D45 00D9630341305 IC MM74HCT244 K067680200010S
D47-56 00D9630341305 IC MM74HCT244 K067680200010S
ZD101 00D9630382500 D,ZENER 0.2W 5.1V UDZ K06605R14P400S
CAPACITORS GROUP
C01 nsp C,CERAMIC 1000PF-K/50V
D011102777160S
C02-05 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C06,07 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C08-14 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C15-17 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C18,19 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C20 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C21 nsp C,CERAMIC 100PF-J/50V D010101167160S
C22 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C23 nsp C,CERAMIC 100PF-J/50V D010101167160S
C24,25 00D9630338509 C,ELECT 10UF-MVG/16V D050100083460S
C26,27 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C28H 00D9630338509 C,ELECT 10UF-MVG/16V D050100083460S
C29H 00D9630338509 C,ELECT 10UF-MVG/16V D050100083460S
C30H 00D9630338509 C,ELECT 10UF-MVG/16V D050100083460S
C87,88 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C831D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C832D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C833D nsp C,CERAMIC 100PF-J/50V D011101167101S
