Rear panel
See the page indicated in parentheses ( ).
q w e r t y u
iQ0 o
Q1
q FM/AM antenna terminals ····················································· (11)
w Analog audio connectors ·············································· (9, 10, 11)
e PRE OUT connectors ··························· (C 6, 34, 35, 36, 37, 38)
r S-VIDEO/VIDEO connectors ··········································· (8, 9, 10)
t COMPONENT VIDEO connectors ········································· (8, 9)
y Speaker terminals ······························· (C 6, 34, 35, 36, 37, 38)
u Power cord ········································································· (C 5)
i HDMI connectors ··························································· (C 3, 7)
o Digital audio connectors ······················································· (8, 9)
Q0 REMOTE CONTROL jacks ······················································· (12)
Q1 DOCK CONTROL jack ······························································ (10)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
