72
72
AVR-1804/884 / AVC-1880
EK 1
E2A 1
E1C 1
EUT 1
E1K 1
N1
34 DSP P.W.B ASSY 1
C-VIDEO P.W.B ASSY E3,EU 1
E2 1
EK 1
E2A 1
E1C 1
EUT 1
E1K 1
N1
33 C-VIDEO P.W.B ASSY 1
38 CPU-CNT P.W.B ASSY 1
48 1CH-AMP P.W.B ASSY 1
53 MULTI OUT P.W.B ASSY E3,EU 1
54 OUTLET(E3) P.W.B ASSY E3,EU,EUT,N 1
1 FRONT PANEL E3 1
FRONT PANEL EU 1
FRONT PANEL E2(Black model),EK 1
FRONT PANEL Silver model 1
FRONT PANEL E2A 1
FRONT PANEL E1C,EUT,E1K 1
FRONT PANEL N 1
2 POWER BUTTON Black model 1
POWER BUTTON Silver model 1
POWER BUTTON Gold model 1
3WINDOWE3,EU1
WINDOW E2,EK,E2A 1
WINDOW E1C,EUT,E1K 1
WINDOW N 1
4 VOLUME KNOB Black model 1
VOLUME KNOB Silver model 1
VOLUME KNOB Gold model 1
5 SELECT KNOB Black model 1
SELECT KNOB Silver model 1
SELECT KNOB Gold model 1
6LENS 2
7 INNER PANEL(BK) E3,EU 1
INNER PANEL(BK) E2(Black model),EK 1
INNER PANEL(SILVER) Silver model 1
INNER PANEL(GO) E2A,E1C,EUT,E1K 1
INNER PANEL(GO) N 1
11 HEAT SINK BRACKET F 1
12 POSISTOR P43T7D330BW16 1
13 TRANSISTOR 2SB1560Y Q102C,FL,FR,SL,SR 5
14 TRANSISTOR 2SD2390Y Q101C,FL,FR,SL,SR 5
15 TRANSISTOR 2SD947F Q103C,FL,FR,SL,SR 5
16 HEAT SINK 1
17 HEAT SINK BRACKET B 1
18 TOP COVER Black model 1
TOP COVER Silver model 1
TOP COVER Gold model 1
20 MAIN CHASSIS 1
21 FOOT ASSY E3,U,2(Black),K,2A,1C,UT,1K 4
FOOT ASSY Silver model 4
FOOT ASSY N 4
22 CARD SPACER 2
Ref. No. Part No. Part Name Remarks Q'ty New
To Next Page
