AVR-2805/985/AVC-2890
CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK
CH1: D-DATA
(IC511 (5) )
1
CH1: DATA
CH2: fs
CH3: 64fs
CH4: 256fs
3
CH1: DATA
CH2: fs
CH3: 64fs
2
INPUT
COAXIAL-1
COAXIAL-2
OPTICAL-1
OPTICAL-2
OPTICAL-3
OPTICAL-4
OPTICAL-3
OPTICAL-4
INPUT
Wave form
IC511
IC513
DIR
SN74HC
LC89057W
RDATA (21)
SLRCK (23)
SBCK (22)
(4) RX2
RMCK (16)
RBCK (17)
RLRCK (20)
ADIN (24)
12.288MHz
(29) XIN
151APW
244APW
(94) DAI_P20
(78) DAI_P11
(79) DAI_P12
(71) DAI_P9
(77) DAI_P10
DAI_P16 (86)
DAI_P15 (82)
DAI_P14 (81)
DAI_P13 (80)
CODEC
Selector
ADSP-21266
IC515
BUFFER
DSP
DATA
fs
fs
64fs
64fs
256fs
IC906
DSDATA1 (41)
DSDATA2 (42)
DSDATA3 (43)
DSDATA4 (44)
(38) DBCLK
(37) DLRCK
(46) ALRCK
(45) ABCLK
(49) ASDATA
(47) MCLK
AD1835
I²SMODE
IC611
74LVX
157MTC
(02) (03)
(05) (06)
(11) (10)
(14) (13)
(04)
(07)
(09)
(12)
IC610
GND
SN74LV
(2)- -(18)
(13)- -(7)
(11)- -(9)
(15)- -(5)
(17)- -(3)
(4)- -(16)
(6)- -(14)
(8)- -(12)
(3)
(2)
(12) (5)
(13)
(14)
(15)
OPTICAL-5
(1)
SELECTOR
OUTPUT
OUTPUT
IC512
IC514
FCX0-03
SN74HC
151APW
(3)
(3)
(1)
(2)
(12)
(13) (5)
(14)
(15)
SELECTOR
1
2
2
3
3
