74
AVR-2805/985/AVC-2890
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
EU : U.S.A. model EC : Canada model E2 : Europe model E2A : Asia model
E1C : China model EUT : Taiwan R.O.C. model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 1U-3469V POWER UNIT ASS'Y for EU,EC 1
1 1U-3469W POWER UNIT ASS'Y for E2,E2A 1
1 1U-3469Y POWER UNIT ASS'Y for E1C 1
1 1U-3469Z POWER UNIT ASS'Y for EUT 1
1 1U-3469X POWER UNIT ASS'Y for JP 1
1-1 POWER UNIT
1-6 PRE OUT UNIT
2 1U-3472V AMP CONNECT UNIT ASS'Y for EU,EC 1
2 1U-3472W AMP CONNECT UNIT ASS'Y for E2,E2A 1
2 1U-3472Y AMP CONNECT UNIT ASS'Y for E1C 1
2 1U-3472Z AMP CONNECT UNIT ASS'Y for EUT 1
2 1U-3472X AMP CONNECT UNIT ASS'Y for JP 1
2-1 REGULATOR UNIT
2-2 AMP CONNECT UNIT
2-3 AC IN UNIT
2-4 EXT.IN CONN.UNIT
2-5 TU CONNECT UNIT
2-6 AUDIO CONN. UNIT
3 1U-3596G CONTROL UNIT ASS'Y for EU,EC 1
3 1U-3596H CONTROL UNIT ASS'Y for E2,E2A 1
3 1U-3596K CONTROL UNIT ASS'Y for E1C 1
3 1U-3596L CONTROL UNIT ASS'Y for EUT 1
3 1U-3596J CONTROL UNIT ASS'Y for JP 1
3-1 CONTROL UNIT
3-3 SELECT UNIT
3-4 TACT 28 UNIT
3-5 COMP.3IN UNIT
3-7 VCONNECT UNIT
4 1U-3601G CONNECT/VIDEO UNIT ASS'Y for EU,EC 1
4 1U-3601H CONNECT/VIDEO UNIT ASS'Y for E2,E2A 1
4 1U-3601K CONNECT/VIDEO UNIT ASS'Y for E1C 1
4 1U-3601L CONNECT/VIDEO UNIT ASS'Y for EUT 1
4 1U-3601J CONNECT/VIDEO UNIT ASS'Y for JP 1
4-1 CONNECT UNIT
4-2 FUNC.SEL UNIT
4-3 S-VIDEO UNIT
4-4 C-VIDEO UNIT
4-5 VOL UNIT
4-6 REMOTE I/O UNIT
4-8 P.SW UNIT
4-9 LED UNIT
4-10 232C UNIT
4-11 H/P UNIT
5 1U-3602G VIDEO CONV. UNIT ASS'Y for EU,EC 1
5 1U-3602H VIDEO CONV. UNIT ASS'Y for E2,E2A 1
5 1U-3602K VIDEO CONV. UNIT ASS'Y for E1C 1
5 1U-3602L VIDEO CONV. UNIT ASS'Y for EUT 1
5 1U-3602J VIDEO CONV. UNIT ASS'Y for JP 1
5-1 CONVERT UNIT
5-2 FLD UNIT
5-3 FLD SUPPLY UNIT
