19
Setting the type of speakers
• The composition of the signals output from the different channels and the frequency response are adjusted automatically according to the
combination of speakers actually being used.
2
At the System Setup Menu select “Speaker Configuration”.
3
Switch to the speaker configuration screen.
4
Set whether or not speakers are
connected and, if so, their size
parameters.
• To select the speaker
• To select the parameter
Center Sp.
Front Sp.
Subwoofer
Surround Sp. A
Surround back Sp.
Surround Sp. B
1
Press “CURSOR/PAGE” at the center of the bottom line on the “AV AMP’s” “SETTING 3/5” page so
that this part is displayed in half-tone dot mesh.
Make the system setups by pushing the jog stick on the remote control unit forward and backward, left
and right.
5
Enter the setting.
a) If no surround speakers are used (if “None” is set for both A and B):
The System Setup Menu reappears.
b) If both surround speakers A and B are used (if either “Large” or “Small” is set for both A and B):
The surround speaker setting screen appears.
c) When “Front” is set to “Large” and “Subwoofer” is set to “Yes”, the set switches to the subwoofer mode.
d) If “None” is set for surround speakers A:
“None” is automatically set for surround speakers B and surround back speaker.
NOTE:
• Select “Large” or “Small” not according to the actual size of the speaker but according to the speaker’s capacity for playing low frequency
(approximately 80 Hz and below) signals. If you do not know, try comparing the sound at both settings (setting the volume to a level low
enough so as not to damage the speakers) to determine the proper setting.
