AVR-1705/685
INPUT-VOL P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC701 00D 963 0096 401 BD3811K1
IC702 00D 963 0114 503 BD3812F
IC721 00D 963 0024 004 NJM2068M
IC761-763 00D 963 0024 004 NJM2068M
IC781-784 00D 963 0024 004 NJM2068M
Q751 00D 963 0121 004 KRC104M
Q752 00D 960 0097 207 KRA102M
Q753,754 00D 960 0196 807 FET 2SK117Y
Q755 00D 963 0121 004 KRC104M
Q756 00D 960 0097 207 KRA102M
Q757,758 00D 960 0196 807 FET 2SK117Y
Q771 00D 963 0121 004 KRC104M
Q772 00D 960 0097 207 KRA102M
Q773,774 00D 960 0196 807 FET 2SK117Y
D751-754 00D 960 0197 000 KDS160
D771,772 00D 960 0197 000 KDS160
ZD701,702 00D 960 0222 603 MTZJ7.5A
RESISTORS GROUP
R731,732 00D 963 9005 668 R,METAL FILM 220-J,1W
R771,772 00D 963 9005 639 R,METAL FILM 100-J,1W
R791,792 00D 963 9005 639 R,METAL FILM 100-J,1W
CAPACITORS GROUP
C701CH 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V for E3, AVR-685
C701CH 00D 963 9003 372 R,CHIP 0-J,1/16W for E2,E1C,EUT
C701L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C701R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C702CH 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V for E3, AVR-685
C702CH 00D 963 9003 372 R,CHIP 0-J,1/16W for E2,E1C,EUT
C702L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C702R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C703CH 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V for E3, AVR-685
C703CH 00D 963 9003 372 R,CHIP 0-J,1/16W for E2,E1C,EUT
C703L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C703R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C704L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C704R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C705L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C705R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C706L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C706R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C707L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C707R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C708L 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C708R 00D 963 9004 575 C,CERAMIC 100PF-J/50V for E2
C711L 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
