Denon AVR-685 User Manual

49
AVR-1705/685
PRE-AMP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q501C 00D 960 0196 603 KTC2874B
Q501FL 00D 960 0196 603 KTC2874B
Q501FR 00D 960 0196 603 KTC2874B
Q501SL 00D 960 0196 603 KTC2874B
Q501SR 00D 960 0196 603 KTC2874B
Q502C 00D 960 0196 205 KSA992F
Q502FL 00D 960 0196 205 KSA992F
Q502FR 00D 960 0196 205 KSA992F
Q502SL 00D 960 0196 205 KSA992F
Q502SR 00D 960 0196 205 KSA992F
Q503C 00D 960 0196 205 KSA992F
Q503FL 00D 960 0196 205 KSA992F
Q503FR 00D 960 0196 205 KSA992F
Q503SL 00D 960 0196 205 KSA992F
Q503SR 00D 960 0196 205 KSA992F
Q504C 00D 960 0196 506 KSC1845F
Q504FL 00D 960 0196 506 KSC1845F
Q504FR 00D 960 0196 506 KSC1845F
Q504SL 00D 960 0196 506 KSC1845F
Q504SR 00D 960 0196 506 KSC1845F
Q901,902 00D 960 0097 207 KRA102M
ZD341,342 00D 960 0095 500 MTZJ5.1B
LED901 00D 963 0148 605 LED,ROUND SML1216W
RESISTORS GROUP
R509C 00D 960 9005 902 R,METAL 1.2K-J,1/4W
R509FL 00D 960 9005 902 R,METAL 1.2K-J,1/4W
R509FR 00D 960 9005 902 R,METAL 1.2K-J,1/4W
R509SL 00D 960 9005 902 R,METAL 1.2K-J,1/4W
R509SR 00D 960 9005 902 R,METAL 1.2K-J,1/4W
R511C 00D 960 9004 301 R,METAL 47-J,1/4W
R511FL 00D 960 9004 301 R,METAL 47-J,1/4W
R511FR 00D 960 9004 301 R,METAL 47-J,1/4W
R511SL 00D 960 9004 301 R,METAL 47-J,1/4W
R511SR 00D 960 9004 301 R,METAL 47-J,1/4W
R901,902 00D 960 9009 270 R,METAL 470-J,2W
CAPACITORS GROUP
C341,342 00D 963 9004 546 C,CERAMIC 0.01UF-M/16V
C501C 00D 963 9006 382 CAP.E. 22UF/25V
C501FL 00D 963 9006 382 CAP.E. 22UF/25V
C501FR 00D 963 9006 382 CAP.E. 22UF/25V
C501M 00D 963 9006 308 CAP.E. 10UF/50V
C501SL 00D 963 9006 382 CAP.E. 22UF/25V
C501SR 00D 963 9006 382 CAP.E. 22UF/25V
C502C 00D 963 9006 308 CAP.E. 10UF/50V
C502FL 00D 963 9006 308 CAP.E. 10UF/50V
C502FR 00D 963 9006 308 CAP.E. 10UF/50V
