Denon AVR-X2500H User Guide

The removable external antennas are required for both Bluetooth and Wireless network connectivity. Please make sure to connect
the antennas before attempting to use the Bluetooth or Wi-Fi features of the AVR-X2500H.
Connecting the external antennas for Bluetooth / Wireless connectivity
For each of the two antennas:
1. Place the antenna evenly over the antenna terminal located at the upper left or right corner of the rear panel.
2. Turn the antenna clockwise until it is fully connected. Do not over tighten.
3. Rotate the antenna upwards for the best possible reception.
Setup
There are four steps to the setup process.
1. Installing batteries in the remote control unit
2. Connecting the receiver
3. Following the On-Screen Setup Assistant
4. Downloading the Mobile Apps
1 Installing batteries in the remote control unit
2 Connecting the receiver
1) Place the receiver near your TV and connect the power cord TV

Denon AVR-X2500H Specifications

General

HDMI in	8
Composite video in	2
Ethernet LAN (RJ-45) ports	1
AirPlay	No
Display	-
Sample rate	196 kHz
HDCP version	2.2
Product color	Black
Audio decoders	DSD, DTS-HD, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
RS-232 interface	Yes
Connectivity technology	Wired & Wireless
Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	8 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	185 W
Power output per channel (20-20KHz@8 Ohm)	95 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	500 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
Supported graphics resolutions	3840 x 2160

Weight and Dimensions

Depth	340.3 mm
Width	434.3 mm
Height	167.6 mm
Weight	9389 g
