14
RCD-M37 / RCD-M37DAB / D-E500 / D-M37
7.
SPK UNIT
(1)
Remove the screws.
（ねじをはずす。
）
(2)
Disconnect the connector wires.
（コネクタワイヤーをはずす。
）
8.
GUIDE UNIT
(1)
Remove the screws.
（ねじをはずす。
）
proceeding
(手
順)
: TOP
CABINET
→
REAR PANEL SUB ASSY
→
SPK UNIT
C
CN92
CN97
CN99
E
proceeding
(手
順)
: TOP
CABINET
→
REAR PANEL SUB ASSY
→
SPK UNIT
:
→
GUIDE UNIT
Bottom
view
13
