30DN-C680
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります
GU-3001B DISPLAY/KEY P.W.B. UNIT ASS'Y
Ref.No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC502 262 3228 908 M66005AFP
IC503 262 1708 909 TC74HC138AF(TP1)
IC504 262 2367 909 NJU3715G (T1)
TR401,402 269 0107 900 RN1241(A/B)TPE4
TR501 269 0082 902 DTC114EKT96
TR502 271 0238 908 2SA1037KT96(S/R)
TR504 271 0238 908 2SA1037KT96(S/R)
D501,502 276 0438 910 MA151A (TAPE)
D503-509 276 0801 903 MA3X717D0L *
D511-514 276 0801 903 MA3X717D0L *
LD503,504 393 9631 903 TLGU1002A(T02) *
LD505 393 9571 911 TLOU1002 (ORG)
LD508 393 9571 911 TLOU1002 (ORG)
LD509 393 9631 903 TLGU1002A(T02) *
LD514-516 393 9631 903 TLGU1002A(T02) *
LD517,518 393 9571 911 TLOU1002 (ORG)
LD521 393 9631 903 TLGU1002A(T02) *
LD523,524 393 9631 903 TLGU1002A(T02) *
LD526-528 393 9631 903 TLGU1002A(T02) *
LD529 393 9571 911 TLOU1002 (ORG)
LD531 393 9631 903 TLGU1002A(T02) *
RESISTORS GROUP
VR405 211 0879 006 V0920B17FA202K
CAPACITORS GROUP
C423,424 257 0010 900 CK73B1H103KT
C425 257 0008 983 CK73B1H102KT
C426 257 0010 900 CK73B1H103KT
C427 257 0014 935 CK73F1E104ZT
! C472 253 8027 702 CK45F2EAC103MC
C504 257 0014 935 CK73F1E104ZT
C505 257 0004 961 CC73SL1H101JT
C506 257 1015 920 CK73F1H104ZT
C507 257 0014 935 CK73F1E104ZT
C508 257 2002 961 CS77B--470MT
C509,510 257 0010 900 CK73B1H103KT
C511 257 0008 983 CK73B1H102KT
C516 257 0008 983 CK73B1H102KT
C526 257 0014 935 CK73F1E104ZT
To Next Page
