Denon DP-200USB Service Manual

DP-200USB
21
Ref No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 941239000410S IC(CE2632,SOP-14) 417-BJR100-830 1 *
IC202 941239000450S IC(MLC3890,TQFP-128) 417-BJR100-831 1 *
IC203 941239000460S IC(1S42S16100E-7TL,TSOP-50,ISSI) 417-BJR100-832 1 *
IC204 941243000350D IC ASS'Y (SST39LF/VF400A,TSOP-48) 704-BJR100-7493 1 *
*
IC205 00D9410049209 IC(BA18BC0FP-E2,3PIN,TO-252-3,SMD) 417-MCDS4-737 1 *
IC206 00D9580048800 IC(TC74HCU04AFN/TC74HCU04FAN(ELP.M)SOP-14) 417-DJ150-419 1 *
IC207 00D9587058204 IC(BA033FP-E2,TO-252-3) 417-CTB200-500 1 *
IC208 00D2623082924 IC(BD4730G-TR,SSOP-5) 417-200USB-931 1 *
Q202,Q203 00D9587057409 CHIP TRANSISTOR(2SC2412KT146R) 416-CDN88-051 2
D201 941209000470S ESD DIODE(RSB6.8S 150mW.6.8V EMD2 ROHM) 414-DJ1100G-207 4
D202 00D9410046901 SWITCHING DIODE(1SS355,UMD2,SMD,TAPING) 414-CD1000-075 1
D203 00D9587056701 DIODE(RB160M-30,SOD-123) 414-900-208 1
D204 00D9587051706 LED (6224-10ID-A,RED ) 410-CD6000-122 1 *
D204 nsp LED HOLDER(LED-3Y,BLACK,H=4.0mm) 504-BJR100-224 2 *
D205 00D9580041807 LED ( GREEN ) 410-CD6000-124 1 *
D205 nsp LED HOLDER(LED-3Y,BLACK,H=4.0mm) 504-BJR100-224 2 *
D206-D208 941209000470S ESD DIODE(RSB6.8S 150mW.6.8V EMD2 ROHM) 414-DJ1100G-207 4
RESISTOR GROUP
R201 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ,50V) 412-CDVD2001-534 3
R202 nsp CHIP RESISTOR(15K OHM,1/10W,0603,J,TP ,50V) 412-007USB-687 4
R203 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ,50V) 412-CDVD2001-534 3
R204 nsp CHIP RESISTOR(15K OHM,1/10W,0603,J,TP ,50V) 412-007USB-687 4
R205-R208 nsp CHIP RESISTOR(470 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-545 6
R209 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-523 2
R210 nsp CHIP RESISTOR(0 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-552 5
R211,R212 nsp CHIP RESISTOR(470 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-545 6
R214 nsp CHIP RESISTOR(1M OHM,1/8W, 0805,J,TP 150V) 412-DV330-308 2
R216 nsp CHIP RESISTOR(10K OHM,1/10W,0603,J,TP ,50V) 412-CDVD2001-534 3
R217 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-530 8
R218 nsp CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-540 4
R219-R221 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-530 8
R222 nsp CHIP RESISTOR(4.7K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-523 2
R223 nsp CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-540 4
R224 nsp CHIP RESISTOR(0 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-552 5
R225 nsp CHIP RESISTOR(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414 2
R226 nsp CHIP RESISTOR(100 OHM,1/8W,J,0805,150V) 412-DV330-304 1
R227-R230 nsp CHIP RESISTOR(100 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-530 8
R231 nsp CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ,50V) 412-CDVD2001-532 2
R232 nsp CHIP RESISTOR(100K OHM,1/10W,0603 ,J,TP ,50V) 412-CDVD2001-537 1
R233 nsp CHIP RESISTOR( 220 OHM,1/8W,0805,J,TP 150V ) 412-DV330-333 2
R234 nsp CHIP RESISTOR(1M OHM,1/8W, 0805,J,TP 150V) 412-DV330-308 2
R235-R237 nsp CHIP RESISTOR(0 OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-552 5
R238 nsp CHIP RESISTOR(47K OHM,1/10W,0603,J,TP ,50V) 412-CDVD2001-532 2
R239,R240 nsp CHIP RESISTOR(39 OHM,1/10W,0603,J,TP ,50V) 412-DCM280-755 2
R241,R242 nsp CHIP RESISTOR(15K OHM,1/10W,0603,J,TP ,50V) 412-007USB-687 4
R243 nsp CHIP RESISTOR(10K OHM,1/8W,0805,J,TP 150V) 412-DV330-306 3
R244-R246 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP 50V) 412-CDVD2001-521 6
R247 nsp CHIP RESISTOR( 220 OHM,1/8W,0805,J,TP 150V ) 412-DV330-333 2
R248,R249 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP 50V) 412-CDVD2001-521 6
R250,R251 nsp CHIP RESISTOR(1K OHM,1/10W, 0603,J,TP,50V) 412-CDVD2001-540 4
R252,R253 nsp CHIP RESISTOR(10K OHM,1/8W,0805,J,TP 150V) 412-DV330-306 3
R255,R254 nsp CHIP RESISTOR(1K OHM,1/8W, 0805,J,TP 150V) 412-DV330-305 2
R256 nsp CHIP RESISTOR(220 OHM,1/10W,0603 ,J,TP 50V) 412-CDVD2001-521 6
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order
replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
REC PCB ASS'Y
NOTE :
When update Firmware, please conrm a last version in SDI.
Use the service board after updating it.

Denon DP-200USB Specifications

General

Type	Belt-drive audio turntable
CD player	No
Product color	Silver
AC adapter frequency	50 Hz
AC adapter input voltage	230 V
Power consumption (typical)	12 W
USB version	2.0
USB ports quantity	1

Weight and Dimensions

Depth	98 mm
Width	360 mm
Height	368 mm
Weight	3200 g
