Denon DP-200USB Service Manual

DP-200USB
29
PARTS LIST OF EXPLODED VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order
replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:The symbols in the column "Remarks" indicate the following destinations.
BKE3 : U.S.A. & Canada model (Black model)
BKE2 : Europe model (Black model) SPE2 : Europe model (Premium Silver model)
Ref.No. Part No. Part Name
Remarks
Q'ty New
9 nsp REC PCB ASS'Y 704-200USB-8134 1 *
10A nsp PH/LI/SPEED/AC SW/AC/DC PCB ASS'Y 1 *
10 - PH/LI PCB ASS'Y 704-200USB-8135
11 - DC PCB ASS'Y 704-200USB-8136
12 - SPEED PCB ASS'Y 704-200USB-8139
1 00D9410012401 CAM GEAR ASS'Y 701-SL24F-192 1
1-1 - CAM GEAR CONTROL ASS'Y 703-SL24F-050 1
1-2 - CAM GEAR 100-SL24F-248 1
1-3 - FRICTION LINK 300-SL24F-130 1
1-4 - ACTUATING LINK 300-SL24F-131 1
1-5 - SPRING 603-SL24F-077 1
1-6 - WASHER 606-F200-006 1
1-7 - CS WASHER (3mm) 606-F200-013 2
1-8 - E-RING WASHER (2mm) 606-B300-029 1
1-9 - WASHER 606-SL24F-057 2
2 nsp PENDULUM ASS'Y 701-SL24F-822 1
2-1 00D9410002204 PENDULUM(S) 100-SL24F-240 1
2-2 00D9410007306 SPRING 603-SL24F-066 1
3 nsp DUST COVER ASS'Y 701-DP29FK-2436 1
3-1 00D9410002709 HINGES ASS'Y (BLUE) 703-B600-026B 1
3-2 00D9410010704 HINGES ASS'Y (YELLOW) 703-B600-030 1
3-3 00D9410001205 DUST COVER 100-DP29FK-325 1
3-4 00D9410008509 RUBBER(S.B.R) 604-B600-026A 2
4 nsp SHAFT ASS'Y 702-SL24F-011 1
4-1 00D9410003407 SHAFT 200-SL24F-116 1
4-2 00D9410009207 E-RING WASHER (3mm) 606-F200-011 1
5 941469000380D RETURM LINK ASS'Y 703-200-1239 1
6 nsp SHAFT ASS'Y 703-L100-063 1
6-1 00D9410010607 CUEING LEVER ASS'Y 703-SL24F-052 1
6-2 00D9410002301 SHAFT HOLDER 100-SL24F-241 1
6-3 00D9410003106 LOCUS SHAFT 200-SL24F-112 1
6-4 00D9410003300 SHAFT 200-SL24F-114 1
6-5 00D9587038606 NUT(M3*P0.5) 601-A100-004 1
6-6 00D9410007005 SCREW 602-SL24F-100 1
6-7 00D9410007704 SPRING 603-SL24F-072 1
6-8 941472000400S SPRING 603-SL24F-078 1
6-9 00D9410009003 RUBBER CAP 604-SL24F-039 1
6-10 00D9410009207 E-RING WASHER (3mm) 606-F200-011 1
6-11 00D9410009702 WASHER( 5.5*3*0.7t) 606-B300-039 1
6-12 00D9410010102 WASHER 606-SL24F-056 1
7 00D9410012304 CENTER&PINION ASS'Y 703-F703-253 1
7-1 - SHAFT & HOLDER ASS'Y 703-SL24F-051C 1
7-2 - SMALL GEAR 100-SL24F-244 1
7-3 - CENTER SHAFT 200-SL24F-105A 1
7-4 - SPINDLE RING 200-SL24F-123 1
7-5 - SCREW(1.7*2.8mm) 602-SL24F-093 1
7-6 - STEEL BALL 607-B600-002 1
8 941684000390S MOTOR ASS'Y (M09S12U13-3,DC9~12V) 704-F706-7303 1
8 - or MOTOR ASS’Y (CCM09-120R2-9) 704-F706-7303 1
8-1 - PULLEY 200-SL24F-109 1
8-2 - MOTOR(M09S12U13-3,DC9~12V) 401-H703-038B 1
8-2 - or MOTOR(CCM09-120R2-9) 401-H703-038A 1

Denon DP-200USB Specifications

General

Type	Belt-drive audio turntable
CD player	No
Product color	Silver
AC adapter frequency	50 Hz
AC adapter input voltage	230 V
Power consumption (typical)	12 W
USB version	2.0
USB ports quantity	1

Weight and Dimensions

Depth	98 mm
Width	360 mm
Height	368 mm
Weight	3200 g
