8
SYS-65HT/SYS-55HT/SC-C65/SC-A65/DSW-65DSW-65 Section
PARTS LIST OF P.W.B. UNIT
※ 本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
PREAMP P.W.B. UNIT ASS’Y
Ref. No Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
Q201-203 00D DSW 33XG 142 TR2SC1815GR 192-027c1815gr
Q205 00D DSW 33XG 144 TR2SA1015GR 192-028a1015gr
Q206-209 00D DSW 33XG 142 TR2SC1815GR 192-027c1815gr
Q210-213 00D DSW 33XG 144 TR2SA1015GR 192-028a1015gr
D201-204 00D DSW 33XG 157 D 1N4002 197-101n4002
D205-210 00D DSW 33XG 156 D 100mA 1N4148/75V 197-031n4148
D211 00D DSW 33XG 157 D 1N4002 197-101n4002
D212-220 00D DSW 33XG 156 D 100mA 1N4148/75V 197-031n4148
D221-223 00D DSW 33XG 157 D 1N4002 197-101n4002
DZ201 00D DSW 33XG 163 ZD 1/2W/3.3V 199-15000335
DZ202,203 00D DSW 33XG 161 ZD 1/2W/12V 199-05001203j
DZ204-206 00D DSW 33XG 159 ZD 1/2W/2.4V 199-05000243j
DZ207 00D DSW 33XG 163 ZD 1/2W/3.3V 199-15000335
CAPACITORS GROUP
C201-204 - ERECTRIC C 10uF/16V 135-3106m16
C205,206 - ERECTRIC C 10uF/25V 135-3106m25
C207,208 - ERECTRIC C 10uF/16V 135-3106m16
C209-215 - CERAMIC C 220P/50V 130-2b221k503
C216 - CERAMIC C 47P/50V 130-2b470k503
C217 - ERECTRIC C 1UF/16V 135-3105m16
C218,219 - ERECTRIC C 220uF/25V 135-3227m25
C220-228 - CERAMIC C 0.1U/50V 130-2f104z503
C229,230 - ERECTRIC C 47U/25V 135-3476m25
C231,232 - ERECTRIC C 10uF/16V 135-3106m16
C233-235 - FILM C 0.1U/63V 129-a104j633
C236 - CERAMIC C 1000P/50V 130-2b102k503
C237 - FILM C 0.22uF/63V 129-a224j633
C238 - FILM C 0.047U/63V 129-a473j633
C239 - ERECTRIC C 100uF/16V 135-3107m16
C240 - ERECTRIC C 4.7U/16V 135-3475m16
C241,242 - ERECTRIC C 10uF/25V 135-3106m25
C243 - ERECTRIC C 22UF/25V 135-3226m25
C244,245 - FILM C 10NF/63V 129-a103j633
C246 - ERECTRIC C 47U/25V 135-3476m25
C247 - CERAMIC C 0.1U/50V 130-2f104z503
OTHER PARTS DROUP
P201 00D DSW 33XG 131 7PIN WIRE/BLK/WHT 162-5015d005
P201 - 5PIN CONNECTOR 175-1c05v01
VR201 00D DSW 33XG 121 VAR R 115-h203b214
VR202 00D DSW 33XG 122 VAR R 115-h503a102
RCA1 00D DSW 33XG 135 RCA-209A/BLK 174-0rca209u
- Washer/t0.5 M5 for RCA1 395-fib-00002
