50
DVD-1920/756
PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (---------) are
not available.
Comparison Chart of Models and Marks
Model Mark
DVD1920BKE3 A
DVD1920SRE3 B
DVD756SRE3 C
Ref. No. Mark Description Funai Parts No. DENON Parts No. Qty New
MECHANICAL PARTS
A1X A FRONT ASSEMBLY 1VM220754 00D 9H2 6000 642 1 *
A1X B FRONT ASSEMBLY 1VM220755 00D 9H2 6000 643 1 *
A1X C FRONT ASSEMBLY 1VM220760 00D 9H2 6000 644 1 *
A2 A TRAY PANEL ASSEMBLY 1VM422186 00D 9H2 6000 645 1 *
A2 B,C TRAY PANEL ASSEMBLY 1VM422188 00D 9H2 6000 646 1 *
A11 INSULATOR ASSEMBLY (R) 1VM420732 00D 9H2 6000 566 1
A12 INSULATOR ASSEMBLY (L) 1VM420733 00D 9H2 6000 567 1
A13 FOOT 0VM406940A 00D 9H2 6000 323 2
A15 CHASSIS 1VM120073 00D 9H2 6000 611 1
A16 A TOP COVER(BLACK) 1VM120074 00D 9H2 6000 612 1
A16 B,C TOP COVER(SILVER) 1VM320865 00D 9H2 6000 613 1
A17 A,B REAR PANEL 1VM220781 00D 9H2 6000 647 1 *
A17 C REAR PANEL 1VM220889 00D 9H2 6000 648 1 *
A21 LABEL SERIAL NO. ---------- - 1
A22 A BAR CODE LABEL ---------- - 1
A22 B BAR CODE LABEL ---------- - 1
A22 C BAR CODE LABEL ---------- - 1
A30 A CONTROL LABEL ---------- - 2
A30 B CONTROL LABEL ---------- - 2
A30 C CONTROL LABEL ---------- - 2
1B1 DVD MECHA N79F1JVM 00D 9H2 6000 649 1 *
2B2 POWER PCB HOLDER 0VM306801 - 1 *
2B3 MAIN PCB HOLDER 1VM320650 - 1 *
2B4 LOADER BASE 0VM101367E 00D 9H2 6000 616 1
2B6 JACK PCB HOLDER 0VM101376 - 1 *
2B16 M-PCB PLATE EARTH 1VM421132 - 2 *
2B34 CUSHION SPACER 1VM422273 - 1 *
2L011 A SCREW C-TIGHT M3X5 BIND HEAD + GBKC3050 00D 9H2 6000 257 5
2L011 B,C SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050 00D 9H2 6000 301 5
2L021 SCREW P-TIGHT 3X12 BIND HEAD+ GBMP3120 00D 9H2 6000 517 4
2L023 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 2
2L041 SCREW B-TIGHT M3X8 BIND HEAD + GBKB3080 00D 9H2 6000 304 8
2L043 SCREW C-TIGHT M3X5 BIND HEAD + GBKC3050 00D 9H2 6000 257 1
2L051 C-TITE SCREW M3*8 BIND GBMC3080 00D 9H2 6000 518 2
2L052 P-TIGHT SCREW 3X8 BIND + GBMP3080 00D 9H2 6000 240 6
2L071 SCREW C-TIGHT M3X5 BIND HEAD + GBKC3050 00D 9H2 6000 301 1
2L101 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 1
2L102 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 4
2L105 P-TIGHT SCREW 3X8 BIND + GBMP3080 00D 9H2 6000 240 3
2L106 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 4
2L107 P-TIGHT SCREW 3X8 BIND + GBMP3080 00D 9H2 6000 240 1
2L108 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 2
