Denon DVD-3800 Service Manual

61
DVD-3800
PARTS LIST OF P.W.B. UNIT ASS'Y
GU-3389A MAIN P.W.B. UNIT
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
SEMICONDUCTORS GROUP
IC101 262 3051 007 IC ES6038
IC102 GEN 6094 ROM sub Ass’y MX29LV160BTC-90
IC103 262 3119 004 IC W986416DH-7
IC104,105 262 2801 902 IC SN74AHCT273PW-EL2
IC106 262 3053 908 IC S-24C02BFJ-TB
IC107 262 2391 904 IC TC7W32F(TE12L)
IC108 262 1953 903 IC TC7WU04F
IC109 262 3052 909 IC SM8701BM
IC110 262 1953 903 IC TC7WU04F
IC111 262 2104 900 IC TC7W14F
IC112 262 3046 902 IC TC7WH157FU
IC113 262 3129 900 IC TC74VHC157AF-EL
IC114 262 2801 902 IC SN74AHCT273PW-EL2
IC115,116 262 2104 900 IC TC7W14F
IC201 262 3054 004 IC MN102H460B
IC202 GEN 6093 ROM sub Ass’y AT49LV1025-70JC
IC203 262 1647 905 IC MN1382-S(TX)
IC206 262 2376 903 IC TC74HCT7007AF(TP1)
IC207 262 3121 005 IC ADSPMEL322
IC208 262 2515 900 IC SN74LV04APW-EL2
IC209 262 2376 903 IC TC74HCT7007AF(TP1)
IC210 GEN 6074 Bass M.ROM sub Ass’y AT49LV002-70TC
IC301 263 1110 901 IC PQ070XZ01ZP
IC302 263 1079 903 IC BA033FP
IC303,304 263 1110 901 IC PQ070XZ01ZP
IC501 262 2802 008 IC TA1293F
IC502 263 0425 901 IC NJM4558M (TAPE)
IC503 263 1109 909 IC AN8471SA
IC504 263 1080 905 IC BA5952AFP
IC505 262 2803 007 IC TC9453F
IC506 262 2892 908 IC 74VHC4066MTC
IC507 262 2877 907 IC 4M DRAM(SOJ)-35
IC508 262 2798 002 IC TC9469BF
IC509 262 2877 907 IC 4M DRAM(SOJ)-35
IC510 263 0615 902 IC BA15218F-DXE2
IC511 GEN 6100 DRV ROM sub Ass’y TMP95FY64F
IC512 263 1079 903 IC BA033FP
IC701 262 3058 000 IC SII504CM208
IC702 262 2916 004 IC 64M SDRAM(TSOP)
IC703 262 3059 902 IC PIC18LC242-I/SO TAPE
IC706 262 3050 008 IC ADV7300
IC708 262 1348 903 IC TC74HC123AF(TP1)
IC709 263 1110 901 IC PQ070XZ01ZP
IC710 262 2977 904 IC BA18BC0FP-E2
IC711 262 3126 000 IC XC2S30-5VQ100C
IC712 262 3127 009 IC XC17S30AV08C(SQZ)
TR501,502 272 0156 902 Transistor 2SB1260-Q
TR503-505 269 0091 906 Transistor DTC143TKT96
TR506 274 0154 007 Transistor 2SD1902(R,S)
TR507 272 0110 003 Transistor 2SB1266(R,S)
TR509 269 0171 907 Transistor IMD3A-T108
TR707 271 0293 901 Transistor 2SA1022-B
TR708,709 272 0125 904 Transistor 2SB709A
D201 276 0717 903 Diode 1SS355 TE-17
D301-303 276 0717 903 Diode 1SS355 TE-17
D501,502 276 0717 903 Diode 1SS355 TE-17
D701 276 0717 903 Diode 1SS355 TE-17
RESISTORS GROUP
R101 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R102-105 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R106 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R107,108 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R109 247 2009 909 Carbon chip 4.7 kohm 1/16W RM73B--472JT (1608)
R111 247 2009 909 Carbon chip 4.7 kohm 1/16W RM73B--472JT (1608)
R113 247 2009 909 Carbon chip 4.7 kohm 1/16W RM73B--472JT (1608)
R116-118 247 2009 941 Carbon chip 6.8 kohm 1/16W RM73B--682JT
R119 247 2009 909 Carbon chip 4.7 kohm 1/16W RM73B--472JT (1608)
R120-125 247 2009 941 Carbon chip 6.8 kohm 1/16W RM73B--682JT
R126 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R127-130 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R131 247 2014 965 Carbon chip 1 Mohm 1/16W RM73B--105JT
R132 247 2006 944 Carbon chip 390 ohm 1/16W RM73B--391JT
R133 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT
R135-137 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT
R143 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R144 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R145,146 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R147,148 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R150,151 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R152-155 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R157 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R158 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R159 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R160 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R163 247 2014 965 Carbon chip 1 Mohm 1/16W RM73B--105JT
R164 247 2005 987 Carbon chip 220 ohm 1/16W RM73B--221JT
R166,167 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT
R169-174 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R177-179 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R180-185 247 2003 989 Carbon chip 33 ohm 1/16W RM73B--330JT
R186,187 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R189-191 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
Note : The symbols in the column “Remarks” indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1 : Asia model
