72
DVD-3800
Ref. No. Part No. Part Name Remarks
Ref. No. Part No. Part Name Remarks
GU-3439 POWER/DISPLAY P.W.B. UNIT
SEMICONDUCTORS GROUP
IC101 262 3048 007 IC ML9207-01GP
IC103 499 0303 004
Remote sensor GP1UM271XK
IC510 262 2580 906 IC CXA1511M
IC511 262 2114 903 IC UPD4721GS-GJG
IC901 265 0112 003 IC STR-F6674
IC902 262 3047 008 IC PC123 Y-22
IC903 263 1113 005 IC SE005N
IC904 263 1048 002 IC BA033T
IC905 263 1114 004 IC PQ1CG21H2FZ
TR101 269 0171 907 Transistor IMD3A-T108
TR102,103 269 0082 902 Transistor DTC114EKT96
TR501 269 0171 907 Transistor IMD3A-T108
TR902 269 0082 902 Transistor DTC114EKT96
TR903 272 0093 010 Transistor 2SB1274 (R/S)
TR904 273 0303 910 Transistor 2SC1740S(S)-T
TR905 269 0083 901 Transistor DTA114EKT96
TR906 269 0082 902 Transistor DTC114EKT96
TR907 275 0106 906 Transistor HAT2053M(TAPE)
TR908,909 274 0036 905 Transistor 2SD468(C)TF
TR910,911 269 0083 901 Transistor DTA114EKT96
TR912 274 0036 905 Transistor 2SD468(C)TF
D102-104 276 0717 903 Diode 1SS355 TE-17
D901-904 276 0729 904 Diode EM01AT (V1)
D905 276 0730 906 Diode AG01ZT (V1)
D906 276 0724 909 Diode SARS01T (V1)
D907-909 276 0730 906 Diode AG01ZT (V1)
D910 276 0725 704 Diode RK39 LF-C4
D911 276 0726 703 Diode RJ43 LF015-305
D912 276 0745 904 Diode RB411DT146
D913,914 276 0727 906 Diode AL01ZT (V1)
D916 276 0717 903 Diode 1SS355 TE-17
D917 276 0737 909 Diode RB161L-40 (TAPE)
D922,923 276 0717 903 Diode 1SS355 TE-17
ZD901 276 0457 904 Zener diode HZS4C-1TD
LD101 393 9623 908 LED SEL2810A(TP7) Amber
LD102 393 9576 903 LED SELU1E10CXM-002 Blue
LD103 393 9504 904 LED SEL1210S(TP7) Red
TH901 279 0044 002 Thermistor NTH11D8R0LA
RESISTORS GROUP
R101 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R102 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R103 247 2005 945 Carbon chip 150 ohm 1/16W RM73B--151JT
R104 247 2005 961 Carbon chip 180 ohm 1/16W RM73B--181JT
R105 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R106 247 2005 945 Carbon chip 150 ohm 1/16W RM73B--151JT
R107 247 2005 961 Carbon chip 180 ohm 1/16W RM73B--181JT
R108 247 2006 915 Carbon chip 270 ohm 1/16W RM73B--271JT
R109 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R110 247 2009 967 Carbon chip 8.2 kohm 1/16W RM73B--822JT
R116 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R118 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R120-122 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R175 244 2051 929 Metal oxide 820 ohm 1W(NB) RM73B--102JT
R176 244 2052 915 Metal oxide 1.8 kohm 1W(NB) RM73B--470JT
R177 244 2055 996 Metal oxide 1.2 kohm 1W(NB)
RS14B3A122JNBST(S)
R178 247 2005 961 Carbon chip 180 ohm 1/16W RM73B--181JT
R179 247 2005 945 Carbon chip 150 ohm 1/16W RM73B--151JT
R180 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R181 247 2008 984 Carbon chip 3.9 kohm 1/16W RM73B--392JT
R529 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R534 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R542 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R544 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R545 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
R546 247 2012 996 Carbon chip 200 kohm 1/16W RM73B--204JT
R547 244 2052 928 Metal oxide 47 ohm 1W(NB)
RS14B3A470JNBST(S)
R549-551 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R552 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R553 247 2011 926 Carbon chip 39 kohm 1/16W RM73B--393JT
R554 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R555-557 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R559 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R561 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R563 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R572-574 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R578 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R580 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT, for E3
R581 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT, for E1
R582,583 247 2011 942 Carbon chip 47 kohm 1/16W
RM73B--473JT, for E2,E1
R584 247 2011 942 Carbon chip 47 kohm 1/16W
RM73B--473JT, for E2,E1
R585 247 2011 942 Carbon chip 47 kohm 1/16W
RM73B--473JT, for E3,E2
R586,587 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT, for E3
R901 244 2675 716 Metal oxide 68 kohm 2W(NB)
RS14B3D683JNBF (ERG)
R902 244 2671 956 Metal oxide 0.47 ohm 2W(NB)
RS14B3DR47JNBST(S)
R905 244 2675 729
Metal oxide 220 kohm 2W(NB)
RS14B3D224JNBF (ERG)
R906 244 2675 703 Metal oxide 47 ohm 2W(NB)
RS14B3D470JNBF (ERG)
R913 244 2043 953 Metal oxide 470 ohm 1W(NB)
RS14B3A471JNBST(S)
R920 244 2051 974 Metal oxide 1 kohm 1W(NB)
RS14B3A102JNBST(S)
To Next Page
