32
RCD-M35DAB/M33
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model EK : U.K. model
E2 : Europe model JP : Japan model
00D1U-3677 MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC301 00D 262 1875 900 BU4066BCF-T1 +C
IC302 00D 262 3181 906 LC75342M
IC303 00D 262 2547 907 LC72720NM for E2,EK,E3
IC305 00D 262 1875 900 BU4066BCF-T1 +C RCD-M35DABEK only
IC401 00D 263 0994 908 BA6287F-E2 +C
IC402 00D 262 3518 009 TMP91FY27UG *
IC403 00D 263 1191 904 TA2157FNG
IC404 00D 263 1220 901 TA2125AFG
IC405 00D 262 3254 008 TC94A20F-010 *
IC406 00D 262 2519 906 SN74LV00APW-EL2 +C
IC407 00D 262 3255 007 TC94A14FAG
IC408 00D 262 3484 904 PCM1741E *
IC409 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC410 00D 263 1129 905 NJM2391DL1-25-TE1 +C
IC411 00D 263 1130 907 NJM2391DL1-33-TE1
IC601 00D 269 0170 005 TOTX178
IC602 00D 263 1093 002 BA05ST RCD-M35DABEK only
! IC603,604 00D 268 0073 905 ICP-N15T
IC605 00D 263 0809 006 NJM7805FA(S)
IC606 00D 263 1229 009 BA033ST RCD-M35DABEK only
IC801 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC802 00D 262 3368 004 M30624FGPGP +C
IC803 00D 263 1189 903 BD4828G-TR +C
IC804 00D 262 3483 905 BR93L66F-W *
IC805 00D 262 3515 909 TC74VHCT00AFT RCD-M35DABEK only *
TR301,302 00D 269 0054 901 DTC144EKT96 +C
TR303 00D 269 0066 902 DTC323TKT96 +C RCD-M35DABEK only
TR304,305 00D 269 0066 902 DTC323TKT96 +C
TR306 00D 269 0066 902 DTC323TKT96 +C RCD-M35DABEK only
TR307,308 00D 269 0054 901 DTC144EKT96 +C RCD-M35DABEK only
TR309 00D 269 0055 900 DTA144EKT96 +C RCD-M35DABEK only
TR310 00D 273 0384 900 2SC2412KT96(S) +C
TR311 00D 273 0384 900 2SC2412KT96(S) +C for E2,EK,E3
TR312 00D 269 0083 901 DTA114EKT96 +C
TR313 00D 269 0082 902 DTC114EKT96 +C
TR401 00D 271 0315 902 2SA1179N
TR402 00D 269 0082 902 DTC114EKT96 +C
TR403 00D 273 0178 912 2SC1740(S)T-70
TR605 00D 273 0483 908 KTC3205Y-AT/P
TR606,607 00D 273 0384 900 2SC2412KT96(S) +C
TR608 00D 269 0082 902 DTC114EKT96 +C
TR609 00D 271 0323 907 KTA1273Y-AT/P
TR803 00D 269 0082 902 DTC114EKT96 +C
TR806 00D 269 0083 901 DTA114EKT96 +C
TR807 00D 269 0082 902 DTC114EKT96 +C
D301,302 00D 276 0717 903 1SS355 TE-17 +C
D304 00D 276 0717 903 1SS355 TE-17 +C
