43
RCD-M35DAB/M33
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model EK : U.K. model
E2 : Europe model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D1U-3677A MAIN A UNIT ASS'Y RCD-M35DABEK only 1 *
1 00D1U-3677B MAIN B UNIT ASS'Y for E2,EK 1 *
1 00D1U-3677C MAIN C UNIT ASS'Y for E3 1 *
1 00D1U-3677D MAIN D UNIT ASS'Y for JP 1 *
1-1 POWER/CD UNIT
1-2 I/O UNIT
1-3 JUNCTION UNIT
2 00D1U-3678 ETC UNIT ASS'Y 1 *
2-1 P AMP1 UNIT
2-2 P AMP2 UNIT
2-3 DISPLAY UNIT
2-4 OUTPUT UNIT
3 00D 411 2059 026 MAIN CHASSIS 1 *
4 00D 104 0317 008 FOOT 4
5 00D 461 1066 002 FELT 4
6 00D 412 5221 207 MECHA HOLDER 1 *
7 00D 443 9015 002 P.W. SPACER 2
8 00D 412 5014 100 TRANS BRACKET 1
! 9 00D 233 6493 004 POWER TRANS(MAIN E2) for E2,EK 1 *
! 9 00D 233 6494 003 POWER TRANS(MAIN E3) for E3 1 *
! 9 00D 233 0692 005 POWER TRANS(MAIN J) for JP 1 *
10 00D 415 0963 103 SAFETY COVER 1 *
11 00D 477 0096 010 PUSH RIVET 3
12 00D 412 5243 007 SHIELD PLATE 1 *
13 00D 216 0128 008 DAB TUNER(EK) RCD-M35DABEK only 1 *
14 00D 412 5249 001 SHIELD CASE (DAB) RCD-M35DABEK only 1 *
15 00D 203 0758 003 COAX CABLE (1.5D) RCD-M35DABEK only 1 *
16 00D 205 1351 007 1P RF CONN. PLUG RCD-M35DABEK only, L-115 1 *
17 00D 412 5240 000 PWB HOLDER RCD-M35DABEK only 2 *
18 00D 417 0683 007 HEAT SINK 1*
19 00D 263 0801 004 NJM7812FA(S) IC603 1
20 00D 263 1221 007 BA80BC0T IC604 1 *
21 00D 412 5222 002 PWB BRACKET (A) 1 *
22 00D 203 4804 076 3P PH-PH SHIELD WIRE CY038 L=240 1 *
23 00D 412 5223 001 PWB BRACKET (B) 1 *
24 00D 105 1477 050 REAR PANEL RCD-M35DABEK only 1 *
24 00D 105 1477 063 REAR PANEL for E2,EK 1 *
24 00D 105 1477 021 REAR PANEL for E3 1 *
24 00D 105 1477 034 REAR PANEL for JP 1 *
25 00D 216 0125 001 AM FM TUNER(E2) for E2,EK 1
25 00D 216 0129 007 AM FM TUNER(E3 RDBS) for E3 1 *
25 00D 216 0127 009 AM FM TUNER(J) for JP 1
26 00D 009 0207 059 15P FFC(1.25) CY152 L=40 1 *
27 00D 001 0026 087 WIRE CORD RCD-M35DABEK only, L=50 1
! 28 00D 206 2128 009 AC CORD W/CON EK for EK 1
! 28 00D 206 2089 106 AC CORD W/CON E2 for E2 1
! 28 00D 206 2160 009 AC CORD VH N/I E3 for E3 1
! 28 00D 206 2085 003 AC CORD W/CON DOM for JP 1
29 00D 445 0056 008 CORD BUSH 1
30 00D 415 0585 015 UL TUBE(16) BK L=30 for E2,EK,E3 1
30 00D 415 0790 046 UL TUBE(16) BK for JP 1
31 00D 337 0100 006 CD MECHA(CD11FTA3N) 1
32 00D 009 0219 018 16P FFC(P1.0-T0.1) CX162:100mm 1 *
33 00D 203 4804 063 3P PH-PH SHIELD WIRE CX034 L=240 1 *
34 00D 204 0567 019 6P PH-PH CON.CORD CX062 L=130 1 *
35 00D 203 8533 013 5P PH-PH CON.CORD CX052 L=200 1 *
