The following factors are of influence to noise
production:
– the material to be cut
– the type of the cutting disc
– the feed force
Take appropriate measures for the
protection of hearing.
Residual risks
The following risks are inherent to the use of these
machines:
– injuries caused by touching the rotating parts
– injuries caused by disruption of the cutting disc
These risks are most evident:
– within the range of operation
– within the range of the rotating machine parts
In spite of the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These are:
– Impairment of hearing.
– Risk of accidents caused by the uncovered parts
of the rotating cutting disc.
–
–
Risk of injury when changing the disc.
Risk of squeezing fingers when opening the guards.
Package contents
The package contains:
1 Chopsaw
1 Cutting disc
1 Allen key
1 Instruction manual
1 Warranty card
1 Service Address card
• Check for damage to the tool, parts or
accessories which may have occurred during
transport.
• Take the time to thoroughly read and understand
this manual prior to operation.
Description (fig. A)
Your D28700 chopsaw has been designed for the
cutting of variously shaped steel materials.
1 On/off switch
2 Operating handle
4 Guard
3 Carrying handle
5 Cutting disc
6 Spindle lock
7 Material clamp
8 Fence
9 Mounting holes
10 Cutting table
11 Spark deflector
12 Depth stop
13 Lock-down pin
14 Allen key
Electrical safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Your tool is double insulated in
accordance with EN 61029; therefore no
earth wire is required.
Using an extension cable
If an extension cable is required, use an approved
extension cable suitable for the power input of this
tool (see technical data).
The minimum conductor size is 1.5 mm
2
.
When using a cable reel, always unwind the cable
completely. Also refer to the table below.
Conductor size (mm
2
) Cable rating (Amperes)
0.75 6
1.00 10
1.50 15
2.50 20
4.00 25
Cable length (m)
7.5 15 25 30 45 60
Voltage Amperes Cable rating (Amperes)
115 0-2.0 66 66 610
2.1 - 3.4 6 6 6 6 15 15
3.5 - 5.0 6 6 10 15 20 20
5.1 - 7.0 10 10 15 20 20 25
7.1 - 12.0 15 15 20 25 25 -
12.1 - 20.0 20 20 25 - - -
