DeWalt DCC018 User Manual

9
ENGLISH
12
Battery pack
13
High-volume tapered
nozzle
14
Inlet/Deflation port
15
High-pressure tapered
nozzle
16
Inflator needle
17
Presta valve adapter
18
Outlet/Inflation port
19
12V DC vehicle connector
and cord
20
External power connector
(12V DC or ACadapter)
21
Date code
Intended Use
Your DeWALT inflator is designed to be used cordless, in most
vehicles, from the standard 12V DC socket or by the DeWALT
13.8V external power supply to inflate car and bike tyres, balls,
rafts, air mattresses and swimming pool floats, etc. This product
is intended for professional useonly.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT operate the inflator in a paint sprayarea.
This inflator is a professional powertool. DO NOT let children
come into contact with the tool. Supervision is required when
inexperienced operators use thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
or external power supply before making any
adjustments or removing/installing attachments or
accessories. An accidental start-up can causeinjury.

WARNING: Use only DeWALT battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. A)
NOTE: Make sure your battery pack
12
is fullycharged.
To install the battery pack
12
into the inflator, align the battery
pack with the rails inside inflator's battery port and slide it into
the port until the battery pack is firmly seated and ensure that it
does notdisengage.
To remove the battery pack from the inflator, press the release
button
11
and firmly pull the battery pack out of the battery
port. Insert it into the charger as described in the charger
section of thismanual.
Fuel Gauge Battery Packs (Fig. A)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge button.
A combination of the three green LED lights will illuminate
designating the level of charge left. When the level of charge
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Hose and Accessory Storage (Fig. A)
12V DC Vehicle Connector and Cord
• The 12V DC vehicle connector
19
can be stored inside the
storage compartment on the side of theinflator.
High-Pressure Hose
• The high-pressure hose
10
is located on a storage channel
on the side of the unit. Wrap the high-pressure hose inside
the channel and secure in the two clips.
High-Volume Hose
• The high-volume hose
5
is located on a storage channel on
the side of the unit. Wrap the high-volume hose inside the
channel and secure in the two clips.
Accessories
• The accessories
15
,
16
and
17
are stored in snap clips
located on the side of theinflator.
Fitting the Accessories (Fig. A)
The high-volume hose
5
comes fitted with a standard tapered
nozzle
13
.
The high-pressure hose
10
can be fitted with the following
attachments which can be found on the side storage
compartment panel:
• an inflator needle valve
16
,
• a high-pressure tapered nozzle
15
, and
• a Presta valve adapter
17
.
NOTE: Make sure each of these adapters are firmly locked in
place before turning the on theinflator.
Fitting the High-Volume Hose (Fig. B)
• Remove the high-volume hose
5
from its storagelocation.
• Line up the notches of the hose with the nubs 
22
of the high
volume pump outlet/inflation port
18
. Then, slide the hose
on and twist counter-clockwise tosecure.
• To remove, twist the hose clockwise and slide hoseoff.
Many inflatables have an internal flap that prevents air loss
during inflation, especially air mattresses. Unless this flap is
displaced by the nozzle the inflatable will not inflate. Push the
nozzle firmly into the valve to make sure that you push this flap
out of theway.
LED Worklight (Fig. A)
An LED worklight
1
is located on the handle of the inflator. To
turn the worklight on, first power the unit by pressing the power
switch
2
, then press the light switch
4
on the front of the
inflator. The inflator will turn off after two minutes of idle time,
including the light. To turn the worklight off, press the light
switch
4
again.
