Intended Use
These drills/drivers/hammerdrills are designed for
professional drilling, percussion drilling and
screwdriving applications. Do not use under wet
conditions or in the presence of flammable liquids or
gases.
These drills/drivers/hammerdrills are professional power
tools.
Do not let children come into contact with the tool.
Supervision is required when inexperienced operators
use this tool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills
unless they are supervised by a person responsible
for their safety. Children should never be left alone
with this product.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack before
making any adjustments or removing/ installing
attachments or accessories. An accidental
start
‑
up can cause injury.
WARNING: Use only DeWALT battery packs and
chargers.
Inserting and Removing the Battery
Pack from the Tool (Fig. B)
nOTE: Make sure your battery pack 1 is fully charged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack 1 with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly
seated in the tool and ensure that you hear the lock
snap into place.
To Remove the Battery Pack from the Tool
1. Press the release button 2 and firmly pull the battery
pack out of the tool handle.
2. Insert battery pack into the charger as described in the
charger section of this manual.
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level
of charge remaining in the battery pack.
To actuate the fuel gauge, press and hold the fuel gauge
button . A combination of the three green LED lights
will illuminate designating the level of charge left. When
the level of charge in the battery is below the usable
limit, the fuel gauge will not illuminate and the battery
will need to be recharged. nOTE: The fuel gauge is only
an indication of the charge left on the battery pack. It
does not indicate tool functionality and is subject to
variation based on product components, temperature
and end‑ user application.
Belt Hook and Magnetic Bit Holder
(Fig. A)
(Optional Accessories)
WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
objects from the belt hook. ONLY hang tool’s belt
hook from a work belt.
WARNING: To reduce the risk of serious
personal injury, ensure the screw holding the
belt hook is secure. iMPORTAnT: When attaching or
replacing a belt hook or magnetic bit holder, use only the
screw that is provided. Be sure to securely tighten the
screw.
A belt hook 11 and magnetic bit holder 13 can be be
attached to either side of the tool using only the screw
12 provided, to accommodate left‑ or right‑ handed
users. If the hook or magnetic bit holder is not desired at
all, it can be removed from the tool.
To move belt hook or magnetic bit holder, remove the
screw 12 that holds it in place then reassemble on the
opposite side. Be sure to securely tighten the screw.
