ENGLISH
13
LED Indications
INDICATION USER ACTION LEDs EXAMPLE
Unit Power
Unit ON Press ON/OFF button All 3 LEDs light in green for 1 second.
GREEN
Unit OFF Press ON/OFF button All 3 LEDs light in red for 1 second.
RED
USB
Plug tool into computer
via USB
Maintenance LED lights in blue continuously.
NOTE: Indication is permanent as soon as tool is plugged in via USB.
BLUE
Battery
Full Charge Battery LED lights in green continuously.
NOTE: Indication is permanent as soon as tool is switched on.
GREEN
Medium
Charge
Battery LED lights in yellow continuously.
NOTE: Indication is permanent as soon as tool is switched on.
YELLOW
Low Charge Battery LED lights in red for 10 seconds, then tool turns off automatically.
NOTE: Indication is permanent as soon as tool is switched on.
RED
Crimp/Press Cycle
Cycle
Complete
Attempt a crimp/press Cycle Complete LED flashes in green for 5 seconds.
GREEN
Cycle Not
Complete
Attempt a crimp/press Cycle Complete LED flashes in red for 5 seconds.
NOTE: No action is possible until user presses ON/OFF button.
RED
Maintenance
Maintenance
Warning
Maintenance LED lights in yellow continuously.
NOTE: 500 cycles left. Indication is permanent as soon as tool is
switched on.
YELLOW
Final
Maintenance
Warning
Maintenance LED flashes in yellow continuously.
NOTE: 100 cycles left. Indication is permanent as soon as tool is
switched on.
YELLOW
Needs Service Maintenance LED lights in red for 10 seconds, then tool turns
off automatically.
NOTE: 0 cycles left.
RED
Temperature
Temperature
Out of Range
Maintenance and Cycle Complete LEDs light in red continuously.
NOTE: Indication is permanent as soon as tool is switched on.
LEDs turn off when acceptable temperature is reached.
RED
