DeWalt DCH273P2 User Manual

15
English
• Always hold the tool firmly with both
hands and ensure a secure stance.
Always operate the tool with the side
handle properlymounted.
WARNING: To reduce the risk of
serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments
oraccessories.
Proper Hand Position (Fig.1, 6)
WARNING: To reduce the risk of
serious personal injury, ALWAYS
use proper hand position as shown
in figure6.
WARNING: To reduce the risk of
serious personal injury, ALWAYS
hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the
main handle(H), with the other hand on the side
handle(E).
Drill Operation (Fig.1)
WARNING: To reduce the risk of
serious personal injury, turn tool off
and disconnect tool from power
source before making any adjustments
or removing/installing attachments
oraccessories.
WARNING: To reduce the risk of
personal injury, ALWAYS ensure
workpiece is anchored or clamped
firmly. If drilling thin material, use a wood
“back-up” block to prevent damage to
thematerial.
HAMMERDRILLING (FIG.1)
1. Set the mode selector switch(C) to the "rotary
hammering"position.
2. Insert the appropriate drill bit. For best results
use high quality carbide-tippedbits.
3. Adjust the side handle(E) asrequired.
4. Mark the spot where the hole is to bedrilled.
5. Place the drill bit on the spot and switch on
thetool.
ROTARY DRILLING (FIG.1)
1. Set the mode selector switch(C) to the "rotary
drilling"position.
2. Depending on your tool, follow either of the
following instructions:
WARNING: Never use standard chucks
in the rotary hammeringmode.
Overload Clutch
There are two different types of overload clutch
fitted. The DCH143, DCH243, DCH253 and
DCH254 have a mechanical overload clutch, the
DCH273 and DCH274 have an electronic overload
clutch fitted.
In case of jamming of a drill bit, the drive to the
drill spindle is interrupted. On units fitted with a
mechanical clutch the indication that the clutch has
activated will be an audible ratcheting together with
increased vibration. If the electronic clutch activates
the motor is repeatedly switched on and off for a few
seconds to replicate the feedback associated with a
mechanical clutch. Release and depress the trigger
to re-engage drive.
Because of the resulting forces, always hold the tool
with both hands and take a firmstance.
Dust Extraction System (Fig.1)
A dedicated integrated dust extraction
system (D25303DH) is available and can be
purchasedseparately.
To operate the D25303DH uses an electrical
connection(T) to the rotary hammer.
The DCH253, DCH254 (TYPE 2 Only), DCH273,
and DCH274 rotary hammer models are equipped
with the electrical connection(T).
NOTE: The D25303DH is not compatible with
the DCH143, DCH243 or TYPE 1 versions of the
DCH253 and DCH254.
The DCH274 is available supplied complete with a
D25303DH and extended kit box as the DCH275.
OPERATION
Instructions for Use
WARNING:
• Always observe the safety instructions
and applicableregulations.
• Be aware of the location of pipework
andwiring.
• Apply only a gentle pressure to
the tool (approx. 5 kg). Excessive
force does not speed up drilling but
decreases tool performance and may
shorten toollife.
• Do not drill or drive too deep to
prevent damage to the dust cover(O).

DeWalt DCH273P2 Specifications

General

Voltage	18V
Max Impact Energy	2.1 J
Chuck Type	SDS-Plus
Battery Included	Yes
Battery Capacity	5.0 Ah
Max. Drilling Capacity [Concrete]	24 mm
Max. Drilling Capacity [Steel]	13 mm
Tool Holder	SDS-Plus
Maximum Concrete Drilling Diameter	24 mm
Impact Energy	2.1 J
Vibration Control	Yes
Included Accessories	Charger
Battery Type	Li-Ion
Type	Cordless Rotary Hammer
Hammering Mode	Rotary Hammer
No Load Speed	0-1, 100 rpm

Summary

Technical Data

Noise and Vibration Total Values

Details noise and vibration levels measured according to EN60745-2-6.

Drilling into Concrete

Vibration emission values for drilling into concrete.

Chiselling

Vibration emission values for chiselling operations.

Drilling into Metal

Vibration emission values for drilling into metal.

Screwdriving

Vibration emission values for screwdriving operations.

Definitions: Safety Guidelines

DANGER Signal Word

Defines the DANGER signal word for imminently hazardous situations.

WARNING Signal Word

Defines the WARNING signal word for potentially hazardous situations.

CAUTION Signal Word

Defines the CAUTION signal word for potentially hazardous situations.

NOTICE Signal Word

Defines the NOTICE signal word for practices not related to personal injury.

Electrical Shock Symbol

Symbol indicating risk of electric shock.

Fire Symbol

Symbol indicating risk of fire.

General Power Tool Safety Warnings

WORK AREA SAFETY

Guidelines for maintaining a safe and clean work environment.

ELECTRICAL SAFETY

Precautions for safe electrical connection and use of the tool.

PERSONAL SAFETY

Recommendations for operator safety, including alertness and PPE.

POWER TOOL USE AND CARE

BATTERY TOOL USE AND CARE

SERVICE

Additional Safety Instructions for Rotary Hammers

Wear Ear Protectors

Recommendation to wear ear protection due to noise exposure.

Use Auxiliary Handles

Importance of using auxiliary handles for control.

Insulated Gripping Surfaces

Use insulated surfaces when contacting live wires.

Secure Workpiece

Secure the workpiece using clamps or other methods.

Wear Eye Protection

Recommendation to wear safety goggles for eye protection.

Residual Risks

Injuries from Touching Parts

Risk of injury from touching rotating or hot tool parts.

Impairment of Hearing

Potential risk of hearing impairment due to noise.

Risk of Squeezing Fingers

Hazard of squeezing fingers when changing accessories.

Health Hazards from Dust

Health risks associated with breathing dust.

Markings on Tool

Read Instruction Manual

Pictogram indicating to read the instruction manual before use.

Wear Ear Protection Symbol

Pictogram indicating requirement for ear protection.

Wear Eye Protection Symbol

Pictogram indicating requirement for eye protection.

Important Safety Instructions for All Battery Chargers

WARNING: Shock Hazard

Warning regarding shock hazard from liquids in charger.

WARNING: Residual Current Device

Recommendation for using a residual current device.

CAUTION: Burn Hazard

Caution regarding burn hazard when charging batteries.

CAUTION: Child Supervision

Caution to supervise children around the charger.

NOTICE: Foreign Material

Notice about keeping foreign material away from charger.

Chargers

Charging Procedure

Step-by-step instructions for charging a battery pack.

Charging Process

Explanation of charger indicators and charge status.

Important Safety Instructions for All Battery Packs

HOT/COLD PACK DELAY

Charger feature that suspends charging for temperature-sensitive batteries.

LITHIUM-ION BATTERY PACKS ONLY

Information on the electronic protection system for Li-Ion battery packs.

Transportation

Battery Pack

Storage Recommendations

Guidelines for optimal storage of battery packs.

Labels on Charger and Battery Pack

Explanation of pictographs used on chargers and battery packs.

Package Contents

INTENDED USE

Electrical Safety

Mains Plug Replacement (U.K. & Ireland Only)

ASSEMBLY AND ADJUSTMENTS

Inserting and Removing the Battery Pack

Instructions for installing and removing the battery pack.

FUEL GAUGE BATTERY PACKS

How to check the remaining charge level on battery packs.

Variable Speed Switch

Side Handle

Forward/Reverse Control Button

Worklight

Selecting the Operating Mode

Rotary Drilling

Mode for screwdriving and drilling into steel, wood, and plastics.

Rotary Hammering

Mode for concrete and masonry drilling.

Hammering Only

Mode for light chipping operations.

Active Vibration Control

Belt Hook

SDS Plus® Tool Holder

Replacing SDS Plus® Tool Holder with Keyless Chuck

OPERATION

Instructions for Use

General safety instructions and warnings before operating the tool.

Proper Hand Position

Correct hand positioning for safe and controlled operation.

Drill Operation

Procedures for performing drilling and hammering operations.

SCREWDRIVING

CHIPPING

MAINTENANCE

Lubrication

Information on the lubrication requirements of the power tool.

Cleaning

Instructions for cleaning the power tool and its parts.

CHARGER CLEANING INSTRUCTIONS

Guidelines for safely cleaning the battery charger unit.

Optional Accessories

Protecting the Environment

Rechargeable Battery Pack
