Proper Hand Position (Fig.P)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the spray handle
grip
5
and the other hand on the spray handle
4
.
Installing and Removing the Battery Packs
(Fig.N, O)
This pressure washer is designed to operate on two battery
packs of equal capacity. The pressure washer will not operate
on a single battery pack, and If using different capacity
battery packs, the smaller capacity battery pack, when
depleted, will cause the unit to turn off
NOTE: For best results, make sure your battery packs are
both fullycharged.
To Install the Battery Packs

WARNING: Ensure speed selector switch is in the OFF,
centered position, before installing battery packs.

CAUTION: Unit stops running when the battery port
door is open. If the speed selector switch is in the HI or
LO position the unit will power ON when the battery
port door closes.

CAUTION: Do not hold the trigger when closing the
battery port door.
1. Unlock the battery port door
20
, rotate the battery
port door latch
21
counterclockwise and swing the
battery port door open to access the batteryport.
2. Align the battery packs
34
with the rails inside the
battery port and slide them in until the battery packs
are firmly seated in the tool and ensure that they will
notdisengage.
3. Lock the battery port door
10
, close the battery port
door
20
so it seals to the pressurewasherunit
8
.
4. Rotate the battery port door latch
21
clockwise to lock
the battery port door. Ensure the battery port door is fully
latched into position before startingtool.
NOTE: The unit will not operate if the battery port door is
not fully closed and latched.
To Remove the Battery Packs
1. Rotate the battery port door latch
21
counterclockwise
and pull the battery port door open to access the
battery packs 
34
.
2. Press the battery release buttons
35
on the battery
packs
34
and firmly pull the battery packs out oftool.
3. Insert the batteries into a charger as described in the
charger section of thismanual.
4. Close the battery port door
10
so it seals to the
pressurewasherunit
8
and lock it. Ensure the battery
port door is fully latched into position.
OPERATION

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Removing High Pressure FoamCannon
from Storage (Fig. A)
Always completely empty the high pressure foamcannon
25
before storing.
1. To remove the high pressure foamcannon
25
from the
built in storage space in the pressure washer unit, grasp
the high pressure foamcannon
25
with one hand and
pull it out and away from the pressure washer unit.
2. To place the high pressure foamcannon
25
into its
storage slot, press the high pressure foamcannon
25
firmly into the storage slot until it snaps into the built in
storage space in the pressure washer unit.
3. Ensure that soap bottle
25
is secured into the storage
position by gently tugging on the soap bottle
25
.
2. Securely tighten the suction hose collar
30
byhand.
NOTE: Always disconnect the suction hose afterusage.
3. Place other end of suction hose, with the filter
29
on it,
into a container of fresh water or a fresh water source.
4. Adjust the float ball
28
on the suction hose so the
filter
29
stays covered in theliquid.
5. Select the correct nozzle to be used. Attaching Nozzles
6. After the job being performed is complete, place the
suction hose into a container of clean water and draw the
clean water through the system torinse.
NOTE: When using the suction hose, it may take a few
minutes for the pressure washer to self prime. Ensure the
pressure washer is turned on and the trigger on the spray
wand it being pulled until primed.
Attaching High Pressure FoamCannon
(Fig. M)
1. To connect the high pressure foamcannon
25
to the
spray wand
2
, pull the quick connect collar
3
toward
the spray wand and insert the soap bottle.
2. Release the quick connect collar
3
to lock the high
pressure foamcannon
25
in place.
3. Give the high pressure foamcannon
25
a firm tug after
the quick connect collar has locked intoplace to ensure
the high pressure foamcannon
25
is locked intoplace.
4. To adjust the rate of foam, rotate the pressure control
knob
39
on the top of the high pressure foamcannon
25
counterclockwise for less or clockwise for
morefoam.
NOTE: The soap bottle should be positioned underneath the
spray wand. Do not position the high pressure foamcannon
above the spray wand as this will lead to soap dripping
on the spray wand. The spray tip on the high pressure
foamcannon
25
rotates for vertical or horizontalapplication.
