14
ENGLISH
bevel pawl, remove the retaining screw, the 22.5° bevel pawl and the 30° crown bevel pawl.
Flip the crown bevel pawl so the 33.9° is facing up. Reattach the screw to secure the 22.5°
bevel pawl and the crown bevel pawl. The accuracy setting will not beaffected.
22.5° Bevel Pawls (Fig.J)
Your saw is equipped to rapidly and accurately set a 22.5° bevel, left or right. The 22.5° bevel
pawl
47
can be rotated to contact the crown adjustmentscrew.
Rail Lock Knob (Fig.A)
The rail lock knob
30
allows you to lock the saw head firmly to keep it from sliding on the
rails. This is necessary when making certain cuts or when transporting thesaw.
Depth Stop (Fig.A)
The depth stop
25
allows the depth of cut of the blade to be limited. The stop is useful for
applications such as grooving and tall vertical cuts. Rotate the depth stop forward and adjust
the depth adjustment screw
29
to set the desired depth of cut. To secure the adjustment,
tighten the wing nut
22
. Rotating the depth stop to the rear of the saw will bypass the depth
stop feature. If the depth adjustment screw is too tight to loosen by hand, the provided blade
wrench can be used to loosen thescrew.
Slide Lock Transport Lever (Fig.L1–L3)
Slide Lock Position (Fig.L1)
The slide lock transport lever
61
in forward location locks saw for maximize vertical
cuttingcapacity.
Transport Position (Fig.L2)
The slide lock transport lever
61
in rear location locks saw in the transport position to secure
the saw head during transport and storage. Recommended for relocating or carrying thesaw.
Stow Position (Fig.L3)
When not in use, the slide lock transport lever
61
can be placed in a stow position. The slide
lock lever locks in place using an indent on the back of the lever that slides up the ramp and
falls into the cast pocket
65
. To unlock the lever, slightly pull the lever till it clears out of the
cast pocket and rotateclockwise.
Automatic Electric Brake
Your saw is equipped with an automatic electric blade brake which stops the saw blade within
5seconds of trigger release. This is notadjustable.
On occasion, there may be a delay after trigger release to brake engagement. On rare
occasions, the brake may not engage at all and the blade will coast to astop.
If a delay or “skipping” occurs, turn the saw on and off 4or 5times. If the condition persists,
have the tool serviced by an authorized DeWALT servicecenter.
Always be sure the blade has stopped before removing it from the kerf. The brake
is not a substitute for guards or for ensuring your own safety by giving the saw your
completeattention.
Wireless Tool Control (Fig. A)
CAUTION: Read all saftey warnings, instruction and specifications of the appliance which
is paired with thetool.
Your tool is equipped with a Wireless Tool Control transmitter which allows your tool to be
wirelessly paired with another Wireless Tool Control device, such as a dustextractor.
To pair your tool using Wireless Tool Control, press and hold the trigger switch
1
on the tool
and the Wireless Tool Control pairing button on the seperate device. An LED on the seperate
device will let you know when your tool has been successfullypaired.
Prior to Operation
• Install the base extensions to both sides of the saw's base. Refer to Assembling the Base
Extensionssection.
• Check the protective belt cover for damage and the proper functioning of the lowerguard.
• Make sure to use the kerf plate. Do not operate the machine if the kerf slot is wider than
12mm.
• Install the appropriate saw blade. Do not use excessively worn blades. The maximum
rotation speed of the tool must not exceed that of the sawblade.
• Make sure all locking knobs and clamp handles aretight.
• Use personal protective equipment and connect the saw to an external dustextractor.
• Although this saw will cut wood and many nonferrous materials, these operating
instructions refer to the cutting of wood only. The same guidelines apply to the other
materials. Do not cut ferrous (iron and steel) materials, fibre cement or masonry with this
saw!
• Do not attempt to cut excessively small pieces.
• Secure theworkpiece.
• Allow the blade to cut freely. Do notforce.
• Allow the motor to reach full speed beforecutting.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and applicableregulations.
WARNING: To reduce the risk of serious personal injury, turn tool off and
disconnect battery pack before making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can causeinjury.
Installing and Removing the Battery Pack (Fig. A)
WARNING: Ensure the tool/appliance is in the off position before inserting the
batterypack.
NOTE: For best results, make sure your battery pack is fullycharged.
To install the battery pack
3
into the tool handle, align the battery pack with the rails inside
the tool’s handle and slide it into the handle until the battery pack is firmly seated in the tool
and ensure that it does notdisengage.
To remove the battery pack from the tool, press the release button
4
and firmly pull the
battery pack out of the tool handle. Insert it into the charger as described in the charger
section of thismanual.
Body and Hand Position (Fig. M)
WARNING: To reduce the risk of serious personal injury, ALWAYS use proper hand position
asshown.
WARNING: To reduce the risk of serious personal injury, ALWAYS hold securely in anticipation
of a suddenreaction.
Proper positioning of your body and hands when operating the mitre saw will make cutting
easier, more accurate and safer. Never place hands near cutting area. Place hands no closer
than 100mm from the blade. Hold the workpiece tightly to the table and the fence when
cutting. Keep hands in position until the trigger has been released and the blade has
completely stopped. ALWAYS MAKE DRY RUNS (UNPOWERED) BEFORE FINISH CUTS SO THAT
YOU CAN CHECK THE PATH OF THE BLADE. DO NOT CROSS ARMS, AS SHOWN IN FIGUREM.
Keep both feet firmly on the floor and maintain proper balance. As you move the mitre arm
left and right, follow it and stand slightly to the side of the saw blade. Sight through the guard
louvers when following a pencilline.
Trigger Switch (Fig. N)
To turn the saw on, push the lock‑off lever
41
to the left, then depress the trigger switch
1
.
The saw will run while the switch is depressed. Allow the blade to spin up to full operating
speed before making the cut. To turn the saw off, release the switch. Allow the blade to stop
before raising the saw head. There is no provision for locking the switch on. A hole
52
is
provided in the trigger for insertion of a padlock to lock the switchoff.
Always be sure the blade has stopped before removing it from thekerf.
Dust Extraction (Fig. O)
WARNING: To reduce the risk of serious personal injury, turn tool off, remove the
battery pack, and place lock lever in the transport position before transporting,
making any adjustments, cleaning, repairing, or removing/installing
attachments or accessories. An accidental start‑up can causeinjury.
CAUTION: Never operate this saw unless the dust bag or DeWALT dust extractor is
in place. Wood dust may create a breathinghazard.
Dust from materials such as lead‑containing coatings and some wood types, can be harmful
to one’s health. Breathing‑in the dust can cause allergic reactions and/or lead to respiratory
infections of the user or bystanders. Certain dust, such as oak or beech dust, is considered
carcinogenic, especially in connection with wood treatmentadditives.
Observe the relevant regulations in your country for the materials to be worked. The vacuum
cleaner must be suitable for the material beingworked.
When vacuuming dry dust that is especially detrimental to health or is carcinogenic, use a dust
class M vacuumcleaner.
Your saw has a built‑in dust port
17
that allows an Airlock™ compatible dust collection
system to beconnected.
To Attach the Dust Bag (Fig.P)
1. Fit the dust bag
53
to the dust port
17
as shown in FigureP.
To Empty the Dust Bag (Fig.P)
1. Remove dust bag
53
from the saw and gently shake or tap the dust bag toempty.
2. Reattach the dust bag back onto the dust port
17
.
You may notice that all the dust will not come free from the bag. This will not affect cutting
performance but will reduce the saw's dust collection efficiency. To restore your saw's dust
collection efficiency, depress the spring inside the dust bag when you are emptying it and tap
it on the side of the trash can or dustreceptacle.
Through‑Cutting Operations (Fig. A)
If the slide feature is not used, ensure the saw head is pushed back as far as possible and
the rail lock knob is tightened. This will prevent the saw from sliding along its rails as the
workpiece isengaged.
NOTE: Although this saw will cut wood and many non‑ferrous materials, we will limit our
detailed discussion to the cutting of wood only. The same guidelines apply to the other
materials. DO NOT CUT FERROUS (IRON AND STEEL) MAT ERIALS OR MASONRY WITH THIS
SAW. Do not use any abrasiveblades.
NOTE: Refer to Guard Actuation and Visibility in the Assembly and Adjustments section
for important information about the lower guard beforecutting.
Crosscuts (Fig.A, Q)
A crosscut is made by cutting wood across the grain at any angle. A straight crosscut is made
with the mitre arm at the zero degree position. Set and lock the mitre arm at zero, hold the
wood firmly on the table and against the fence. With the rail lock knob tightened, turn on the
saw by squeezing the trigger switch
1
shown in FigureA.
When the saw comes up to speed (about 1second) lower the arm smoothly and slowly to cut
through the wood. Let the blade come to a full stop before raising arm.
