DeWalt DWE7485 User Manual

13
ENGLISH
ADJUSTMENTS
Blade Adjustment
Blade Alignment (Parallel to Mitre Slot) (Fig.F)

WARNING: Cut Hazard. Check the blade at 0˚ and 45˚
to make sure blade does not hit the throat plate, causing
personalinjury.
If the blade appears to be out of alignment with the mitre slot
on the table top, it will require calibration for alignment. To
realign the blade and mitre slot, use the following procedure:

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
1. Using a 5mm hex wrench, loosen rear pivot bracket
fasteners
32
, located on the underside of the table, just
enough to allow the bracket to move side-to-side.
2. Adjust the bracket until the blade is parallel to the mitre
gaugeslot.
3. Tighten the rear pivot bracket fasteners to 12.5–13.6 Nm.
Blade Height Adjustment(Fig.A)
The blade can be raised and lowered by turning the blade
height adjustment wheel
6
.
Make sure the top three teeth of the blade are just breaking
through the upper surface of the workpiece when sawing. This
will ensure that the maximum number of teeth are removing
material at any given time, thus giving optimumperformance.
Aligning Guard Assembly to Blade (Fig. G)
1. Remove the throat plate. Refer to Removing Throat Plate
underAssembly andAdjustments.
2. Raise the blade to full depth of cut and 0° bevelangle.
3. Locate the three small set screws
33
. These screws will be
used to adjust the riving knifeposition.
4. Lay a straight edge on the table against two blade tips. The
riving knife should not touch the straightedge.
5. If adjustment is needed, loosen the two larger lock
screws
34
.
6. Use the small set screws
33
to adjust the riving knife
position. Lay the straight edge on the opposite side of the
blade and repeat adjustments asneeded.
7. Lightly tighten the two larger lock screws
34
.
8. Place a square flat against the riving knife to verify the riving
knife is vertical and in-line with theblade.
9. If needed, use the set screws to bring the riving knife vertical
with thesquare.
10. Repeat step 4 to verify position of rivingknife. Repeat 5
through9 ifnecessary.
11. Fully tighten the two larger lock screws
34
.
Parallel Adjustment (Fig. A, H, I)
For optimum performance, the blade must be parallel to the
rip fence. This adjustment has been made at the factory. To
re-adjust:
Position 1 Fence Alignment
1. Install the fence in position 1 and unlock the rail lock
lever
5
. Locate both locator pins
47
that support the fence
on the front and rearrails.
2. Loosen the rear locator pin screw and adjust the allignment
of the fence in the groove until the fence face is parallel to
the blade. Make sure you measure from the fence face to
the front and back of the blade to ensurealignment.
3. Tighten the locator screw and repeat on the left side of
theblade.
4. Check rip scale pointer adjustment(Fig.I).
Position 2 Fence Alignment (Fig. H)
1. To align position 2 fence locator pins
47
, ensure
position 1 pins have been aligned, refer to Position 1
FenceAlignment.
2. Loosen the position 2 pins, then using the holes on the
blade wrench
19
as a guide for positioning, align the
pins(Fig.H).
3. Tighten the locator pins(front andrear).
Adjusting the Rip Scale (Fig. H, I)
1. Unlock the rail lock lever
5
.
2. Set the blade at 0° bevel and move the fence in until it
touches theblade.
3. Lock the rail locklever.
4. Loosen the rip scale indicator screws
35
and set the rip
scale indicator to read zero(O). Retighten the rip scale
indicator screws. The yellow rip scale(top) reads correctly
only when the fence is mounted on the right side of the
blade and is in position 1
47
(for 0mm to 510mm ripping)
not the 610mm rip position. The white scale(bottom)
reads correctly only when the fence is mounted on the
right side of the blade and in position 2
47
(for 100mm to
610mmripping).
The rip scale reads correctly only when the fence is mounted to
the right of theblade.
Rail Lock Adjustment (Fig. I, J)
The rail lock has been factory-set. If you need to re-adjust,
proceed as follows:
1. Lock the rail lock lever
5
.
2. On the underside of the saw, loosen the jam nut
36
.
3. Tighten the hex rod
37
until the spring on the locking
system is compressed creating the desired tension on the
rail lock lever. Retighten the jam nut against the hexrod.
4. Flip the saw over and check that the fence does not move
when the lock lever is engaged. If the fence is still loose,
tighten the springfurther.

DeWalt DWE7485 Specifications

General

Push stick	Yes
Idle speed	5800 RPM
Cutting depth (45º)	45 mm
Cutting depth (90º)	65 mm
Cutting width @ parallel guide/rip fence (max)	622 mm
Product color	Black, Grey, Yellow
Input power	- W
Output power	1850 W

Weight and Dimensions

Width	605 mm
Height	330 mm
Weight	22000 g
Table width	485 mm
Spindle bore	30 mm
Blade diameter	210 mm
