7
English
Date Code Position (Fig. 1)
The date code (p), which also includes the year of manufacture,
is printed into thehousing.
Example:
2021 XX XX
Year of Manufacture
Package Contents
The package contains:
1 Angle grinder
1 Guard
1 Side handle (DWE8110S only)
1 Flange set
1 Hex wrench (DWE8110S only)
2 Wrench (DWE8100S & DWE8100T only)
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Description (Fig. 1)
WARNING: Never modify the power tool or any
part of it. Damage or personal injury could result.
a. Spindle lock button
b. Spindle
c. Side handle(DWE8110S only)
d. Backing flange
e. Threaded clamp nut
f. Guard
g. Slider switch(DWE8100S & DWE8110S)
g1. Toggle switch(DWE8100T)
Intended Use
The DWE8100S, DWE8100T, DWE8110S small angle grinders
have been designed for professional grinding, sanding, wire
brushing, polishing and cutting applications.
DO nOT use grinding wheels other than centre depressed
wheels and flap discs.
DO nOT use under wet conditions or in the presence of
flammable liquids orgases.
These heavy-duty angle grinders are professional power tools.
DO nOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the rating plate.
This tool is double insulated; therefore no earth wire
is required. Always check that the power supply
corresponds to the voltage on the rating plate.
WARNING: 115 V units have to be operated via a
fail-safe isolating transformer with an earth screen
between the primary and secondary winding.
If the supply cord is damaged, it must be replaced by a specially
prepared cord available through the DeWALT service organisation.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data). The minimum conductor size is 1.5mm
2
; the
maximum length is30m.
When using a cable reel, always unwind the cablecompletely.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect
tool from power source before making
any adjustments or removing/installing
attachments or accessories. Before reconnecting
the tool, depress and release the trigger switch to
ensure that the tool is off.
Attaching Side Handle (Fig.1)
WARNING: Before using the tool, check that the
handle is tightened securely.
Screw the side handle (c) tightly into one of the holes on either
side of the gear case. The side handle should always be used to
maintain control of the tool at all times.
Accessories and Attachments
It is important to choose the correct guards, backing pads and
flanges to use with grinder accessories. Refer to chart at the end of
this section for information on choosing the correct accessories.
nOTE: Edge grinding and cutting can be performed with Type
27 wheels designed and specified for this purpose.
WARNING: Accessories must be rated for at least
the speed recommended on the tool warning
label. Wheels and other accessories running
over rated accessory speed may burst and cause
injury. Threaded accessories must have a M10 hub
(for DWE8100T, DWE8100S) or a M14 hub (for
DWE8110S). Every unthreaded accessory must have
a 22 mm arbor hole. If it does not, it may have been
designed for a circular saw and should not be used.
Use only the accessories shown in chart at the end of
this section. Accessory ratings must be above listed
minimum wheel speed as shown on tool nameplate.
